ATEX IECEx Explosion Motion Sensor-IN01-A01

• Products Overview:

The explosion-safe motion sensor has been designed for hazardous classified areas(zone 1&2, Zone 21&22) where flammable gases, vapors, mist, fibers, and dust exist. With its robust light metal housing and borosilicate glass lens, it can function normally in harsh environmental conditions. Based on advanced high frequent radar technology, the sensor is capable of detecting even the slightest movements. The optical sensor switches the light ON and OFF at a pre-set time. This sensor makes your lighting system intelligent, convenient, and economical.

• Certifications:

Marking ATEX & IECEx
II 2G Ex db IIC T6 Gb
II 2D Ex tb IIIC T80℃ Db IP66/67
Standards :
EN IEC 60079-0, EN IEC 60079-1,
EN IEC 60079-31;UL1203;
UL 60730-1; CSA 60730-1
Area of Classification (Gas):Zones 1 and 2
Area of Classification (Dust): Zones 21 and 22
Marking UL844 (North American)
Class I, Division 1, Groups A, B, C, D
Class I, Division 2, Groups A, B, C, D
Class II, Division 1, Groups E, F, G
Class II, Division 2, Groups F, G
Class III
Ambient Temperature: 4°F to 104°F(-40℃ to 60℃)
Temperature Classification (Gas): T6
Max. Surface Temperature (Dust): 176°F(80℃)
IP66-IP67

• Technical Information:

(M20, M25)×1.5 plugs and NPT1/2”, NPT3/4” plugs
Rated Voltage: AC120-277V, 50Hz
HF System: 5.8GHz±75MHz, ISM wave band
Hold Time: 5s/30s/90s/3min/20min/30min
Transmitting Power: <0.5mW
Power Consumption: ≤0.5W(standby) 1 2
Housing Material: Copper-free aluminum, plastic-sprayed surface
Daylight Sensor: 5Lux/15Lux/30Lux/50Lux/100Lux/Disable
Detection Sensitivity: 25%/50%/75%/100%
Detection Zone: Max. (D x H): 16m x 15m
Rated Load: 120V@400W; 220-240V@800W; 277V@1000W
Mounting Height: 15m Max.
Motion Detection: 0.5~3m/s
Detection Angle: 150° (wall installation), 360° (ceiling installation)
Connection Thread: Metric Thread and NPT Thread
Type of Flameproof Joint: Threaded Joint

• Dimensions & Packing:

• Setting:

By selecting the combination on the DIP switch, sensor data can be precisely set for each specific application.
Detection area

Detection area can be reduced by selecting the combination on the DIP switches to fit precisely each application.
Hold time

Refers to the time period the lamp remains at 100% illumination after no motion detected.
Daylight sensor

The sensor can be set to only allow the lamp to illuminate below a defined ambient brightness threshold. When set to Disable mode, the daylight sensor will switch on the lamp when motion is detected regardless of ambient light level. 30lux, 50lux,100lux,:twilight operation, 5lux, 15lux: darkness operation only.
Mode

When set to Disable, the microwave sensor function is inactive, lights turns on or off by switch. When set to Sensor, the microwave sensor function is active.

• Detection Pattern:
