Specifications
Brand Name :
CODT
Model Number :
CODT-SL45W/75W/100W/150W/200W/250W/300W-B
Certification :
UL CUL, DLC
Place of Origin :
SHENZHEN CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
500pcs per day
Packaging Details :
58*32*40cm(45W/75W/100W) 77*48*25cm(150W/200W) 92*48*25cm(250W/300W)
Ip rating :
IP66
Working temperature(℃) :
-20 - 55
Working lifetime(hour) :
100000
Cri (ra>) :
80
Lamp luminous efficiency(lm/w) :
155
CCT(K) :
3000 4000 5000 6000
Description

45W 75W 100W 150W 200W 250W 300W Utra-thin high lumen output LED street light

Features:

▪ Ultra slim heat sink design makes the lamp lighter and better in heat dissipation

▪ High lumen SMD5050 chip

▪ Waterproof IP66,high thermal conductivity housing

▪ Beam angle Type II glass lens with transmittance 92%

Specifications:

Technical Data

Model Number CODT-SL45W/75W/100W-B CODT-SL150W/200W-B CODT-SL250W/300W-B
Power 45W/75W/100W 150W/200W 250W/300W
Luminous Efficacy 155lm/W 155lm/W 155lm/W
Lumen Output 6975lm/11625lm/15500lm 22500lm/31000lm 38750lm/46500lm
LED Quantity 40pcs/80pcs/80pcs 120pcs 200pcs/240pcs
Dimension L378*W280*H82mm L570*W379*H111mm L725*W379*H111mm
Luminaire Net Weight 5.1KG/5.2KG/5.4KG
CCT 3000K 4000K 5000K 6000K
CRI >80Ra
System Efficiency ≥90%
Lens Type II

Electrical Details

Input Voltage AC100-277V/347V/480V
Power Frequency 50-60Hz
Output Voltage DC36-48V
Power Efficiency >92%
Power Factor ≥0.95
Total Harmonic Distortion ≤15%
Dimmable Yes (Optional)

Other Details

IP Rating IP66
Lifespan 100,000+ Hours
Storage Temperature -20º~65ºC
Operating Temperature -20º~55ºC
Certification UL,DLC Premium,SAA,TUV,VEET,CB
Color of housing Gray(customized)

Packing Information

Model No. N.G(KG) Carton Size(CM)
CODT-SL45W-B 5.1 58*32*40
CODT-SL75W-B 5.3 58*32*40
CODT-SL100W-B 5.4 58*32*40
CODT-SL150W-B 10.1 77*48*25
CODT-SL200W-B 10.2 77*48*25
CODT-SL250W-B 13 92*48*25
CODT-SL300W-B 13.1 92*48*25

45W 75W Bright Solar Street Lights 100W 150W 200W 250W 300W Utra Thin

45W 75W Bright Solar Street Lights 100W 150W 200W 250W 300W Utra Thin

Quick Details:

1. Tool-free LED Driver Replacement

Independent driver board easy replacement

2. With Buckle

Open the cover free-tool

3. Bubble Level

The level instrument accurates the installation of lamps in one minute
4. Vent
There are two vents with a balanced atmosphere Pressure and moisture prevention

Application:

Widely use in high way, parking lot area, roadway, pathway, square,stadium,residential area,-yard,industrial area and etc.

FAQ:

Q1. Can I have a sample order for led light?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A: 3-5 days for Sample preparing ,8-10 working days for mass production.

Q3. Do you have any MOQ limit for led light order?

A: Low MOQ, 1pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.
