4 Passenger Electric Hunting Buggy With Intelligent Onboard Charger
4 Passenger Electric Hunting Buggy With Intelligent Onboard Charger
4 Passenger Electric Hunting Buggy With Intelligent Onboard Charger
4 Passenger Electric Hunting Buggy With Intelligent Onboard Charger
4 Passenger Electric Hunting Buggy With Intelligent Onboard Charger
4 Passenger Electric Hunting Buggy With Intelligent Onboard Charger
4 Passenger Electric Hunting Buggy With Intelligent Onboard Charger
4 Passenger Electric Hunting Buggy With Intelligent Onboard Charger
Specifications
Brand Name :
Excar
Model Number :
A1S2
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Price :
Negotiate
Payment Terms :
T/T, L/C
Supply Ability :
3000pcs per year
Delivery Time :
7-15 working days
Packaging Details :
20' container or 40' container
Body color :
can be customized
Roof color :
White,black and white
Seat color :
White,black and white
Motor :
ADC motor 48V 3KW
Controller :
Curties controller 48V 275A
Batteries :
Trojan battery
Charger :
Intelligent onboard charger
Transaxle :
Italy graziano axle
Brand :
EXCAR
Description

EXCAR 48V 3KW 4 Seat dune buggy club car golf cart electric cars suv beach buggy car


Steering & suspersion

ItemDescription
Steering SystemSelf-adjusting rack and pinion steering system,
with automatic compensation function
Brake SystemRear wheel mechanical brake
AcceleratorHolzer type, stepless speed change
Front suspensionMcpherson independent spring suspension
Rear suspensionCoil spring hydraulic shock absorber
Driving modelRear axle two stage deceleration, motor direct driving
Wheel & TyreAluminum wheel & USA Carlisle 18*8.5-8 6 layers


Description

ItemDescription
SystemDC systemAC system
ControllerCurtis controller 1266A-5201, 275A, imported from USA directlyCurtis controller 1234E-5221, 275A, imported from USA directly
Motor

ADC brand Separately excited
DC motor 48V 3.7kw

ADC brand Separately excited
AC motor 48V 5kw

BatteryTrojan battery, T875,8V*6pcs, imported from USA directlyTrojan battery, T875,8V*6pcs, imported from USA directly
Transaxle

Italian GRAZIANO axle
with gear ration 1:12

Italian GRAZIANO axle
with gear ration 1:16

Charger

High Frequency onboard charger
48V/17A regulator

High Frequency onboard charger
48V/17A regulator



Performance

ItemDescription
systemDC systemAC system
Passenger Capacity22
Climbing capacity(full load)30%35%
Max. forward speed23km/h45km/h
Endurance mileage70-90km80-90km
Charging time8-10 hours8-10 hours
Max.loading weight360kgs360kgs
Min.turning radius2.9m2.9m
Max. movement after brake at speed of 20km/h≤4m≤4m



* 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;
2) Range will vary depending on temperature, grade, payload and driving style.


Dimensions

ItemDescription
Overall dimensions (L x W x H)3100x1200x2100mm
Ground clearance114mm
Wheelbase1670mm
Front wheel tread (mm)860mm
Rear wheel tread (mm)970mm



Option Accessories

To increase the sales value of our golf cart, we also provide many optional accessories.

ItemOption descriptionItemOption description
1E-key112-point seatbelt
2Hinged windshield12Battery water refill system
3Laminated windshield with wiper13Digital meter
4Steel brush guard14EM brake
5Front steel basket15Four wheel disc brake
6Inner rear view mirror16Carlisle 205/50-10 tyre with10inch wheel
7Side rear view mirror17Ice box
8Enclosure18Sand bottle
9Sunshine cover19Sand rake
10Golf bag cover20Ball washer



Product details

4 Passenger Electric Hunting Buggy With Intelligent Onboard Charger
4 Passenger Electric Hunting Buggy With Intelligent Onboard Charger
4 Passenger Electric Hunting Buggy With Intelligent Onboard Charger

FAQ:

1, what's your warranty time?
Usually for 1 year

2, What's the production time?
Normally for 7-15 working days

3, What's your payment term?
T/T 30% deposit and balance paid before shipment

4, Can we also purchase the parts?
Yes,if you do maintainess service,you can also buy parts from us

5, How do you provide after-sales once customer bought the cart from us?
Once you purchase the cart from us,then i will provide you manual to learn it and tell you how to fix it.
If you need,we can arrange our technist person to fly to your area and help you solve it.
