Specifications
Brand Name :
Excar
Model Number :
A1H2/EC
Certification :
CE
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
Negotiable
Delivery Time :
20 days
Power Fuel :
Electric
Power :
3700W
Voltage of Battery :
48V
F/R Track :
860/970mm
Climbling :
25%
Min Turning Radius :
2.9m
Description

Product Description

Fire Truck China Made Cheap Electric Golf Cart

Cargo Size:2183*1500*1420mm
Item Description
System DC system AC system
Controller Curtis controller 1266A-5201, 275A, imported from USA directly Curtis controller 1234E-5221, 275A, imported from USA directly
Motor ADC brand Separately excited
DC motor 48V 3.7kw		 ADC brand Separately excited
AC motor 48V 3kw
Battery Trojan battery, T875,8V*6pcs, imported from USA directly Trojan battery, T875,8V*6pcs, imported from USA directly
Transaxle Italian GRAZIANO axle
with gear ration 1:12		 Italian GRAZIANO axle
with gear ration 1:16
Charger High Frequency onboard charger
48V/17A regulator		 High Frequency onboard charger
48V/17A regulator

Performance
Item Description
system DC system AC system
Passenger Capacity 2 2
Climbing capacity(full load) 30% 35%
Max. forward speed 23km/h 45km/h
Endurance mileage 70-90km 80-90km
Charging time 8-10 hours 8-10 hours
Max. loading weight 360kgs 360kgs
Min. turning radius 2.9m 2.9m
Max. movement after brake at speed of 20km/h ≤4m ≤4m

* 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;
2) Range will vary depending on temperature, grade, payload and driving style.
Dimensions
Item Description
Overall dimensions (L x W x H) 4000x1200x1800mm
Ground clearance 114mm
Wheelbase 1670mm
Front wheel tread (mm) 860mm
Rear wheel tread (mm) 970mm

Body and Frame
Item Description
Frame & Chassis Aluminum alloy beam, bended
Body PP engineering plastic front and rear body cover, injected
Roof Glass fiber reinforced plastic
Windshield Organic glass (PMMA), one-piece or two pieces
Roof supports Imbedding black coating steel tube in the plastic support
Cushion Reborn sponge with artificial leather and plastic bottom cover
Backrest Reborn sponge with artificial leather and plastic cover
Armrest Plastic
Floor mat Anti-skidding rubber
Rear basket Plastic
Golf bag holder Plastic support with nylon strap
Dashboard Black plastic material, battery power indicator, ignition key on it
Beverage holders 4 pcs cups holders, 2 pcs for each side
Side trim Plastic, black
Score card holder On the steering wheel

Electric Fire Truck 2 Seater CE Approved With Trojan Battery Electric Golf CartsElectric Fire Truck 2 Seater CE Approved With Trojan Battery Electric Golf Carts

Electric Fire Truck 2 Seater CE Approved With Trojan Battery Electric Golf Carts

Electric Fire Truck 2 Seater CE Approved With Trojan Battery Electric Golf Carts

FAQ

1.Can you customize the cart according to our special request?

Yes,we can customize the cart according to your request unless some complex parts we hard to make.

2.What is your MOQ?

You can order just 1 unit .But if your order is big, we will provide you with a discount.

3.Can we put the Logo we designed on the cart?

Yes, you can put your own Logo on the cart.

4.What is your lead time for production?

The typical lead time of our cart is 15 days.

5.What kind of warranty Excar provides?

Non-artificial damaged products,shifting for a year or one year repair.
