Specifications
Brand Name :
Excar
Model Number :
A1S4
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
Negotiable
Delivery Time :
20 days
Model NO. :
A1S4
Power Fuel :
Electric
Gradeability :
20-30%
Controller :
48V/350A Curtis Conroller
Transaxle :
Italy Graziano Axle
Chassis :
Aluminum Chassis
Specification :
48V electric golf cart
Power :
3.7kw
Maximum Speed :
20-30 km/h
Suitable for :
Golf Course/Villa/Tourist Area/Holiday Village
Voltage of Battery :
48V
Motor :
48V 3.7kw ADC Motor
Battery :
USA Trojan T-875 6*8V
Tyre :
Carlisle 18X8.5-8 6 Layers Tyre
Description

Key Components

Item Description
System DC system AC system
Controller Curtis controller 1266A-5201, 275A, imported from USA directly Curtis controller 1234E-5221, 275A, imported from USA directly
Motor ADC brand Separately excited
DC motor 48V 3.7kw		 ADC brand Separately excited
AC motor 48V 3kw
Battery Trojan battery, T875,8V*6pcs, imported from USA directly Trojan battery, T875,8V*6pcs, imported from USA directly
Transaxle Italian GRAZIANO axle
with gear ration 1:12		 Italian GRAZIANO axle
with gear ration 1:16
Charger High Frequency onboard charger
48V/17A regulator		 High Frequency onboard charger
48V/17A regulator

Performance

Item Description
system DC system AC system
Passenger Capacity 4 4
Climbing capacity(full load) 30% 35%
Max. forward speed 23km/h 45km/h
Endurance mileage 70-90km 80-90km
Charging time 8-10 hours 8-10 hours
Max. loading weight 360kgs 360kgs
Min. turning radius 3.9m 3.9m
Max. movement after brake at speed of 20km/h ≤4m ≤4m

* 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;
2) Range will vary depending on temperature, grade, payload and driving style.

Dimensions

Item Description
Overall dimensions (L x W x H) 3175x1219x1727mm
Ground clearance 114mm
Wheelbase 2490mm
Front wheel tread (mm) 860mm
Rear wheel tread (mm) 970mm
