2 Cylinders 1200L Excavator Spare Parts Excavator Attachments Excavator Hydraulic Clamshell Bucket
2 Cylinders 1200L Excavator Spare Parts Excavator Attachments Excavator Hydraulic Clamshell Bucket
2 Cylinders 1200L Excavator Spare Parts Excavator Attachments Excavator Hydraulic Clamshell Bucket
2 Cylinders 1200L Excavator Spare Parts Excavator Attachments Excavator Hydraulic Clamshell Bucket
2 Cylinders 1200L Excavator Spare Parts Excavator Attachments Excavator Hydraulic Clamshell Bucket
2 Cylinders 1200L Excavator Spare Parts Excavator Attachments Excavator Hydraulic Clamshell Bucket
Specifications
Brand Name :
HYKING
Model Number :
QXD120
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
L/C,T/T
Supply Ability :
50 sets/month
Delivery Time :
15 days
Packaging Details :
film,plywood box
Name :
Hydraulic Clamshell Bucket For Excavator
Feature :
High Performance
Bucket capacity :
1200L
Self weight :
740kg
Cylinder :
2 pcs
Color :
Optional
Description

Strong Hydraulic Clamshell Bucket For Excavator , Wheel Excavator Backhoe Clam Bucket

Hydraulic Clamshell Bucket For Excavator Features & Benefits

Materials: High strength alloy plate and high strength wearable board WH60A,WH60C.NM400,HARDOX450. All of the materials makes the bucket become more wear-resisting.

Hydraulic Clamshell Bucket For Excavator Description:

Hydraulic Clamshell Bucket is very popular and ideal in loading,unloading,dredging and excavating works.
Especially for barge docks loading&unloading,clamshell bucket can be very big volume,and high efficient.

Excavator Clamshell bucket grab is easy for installation:
-if no rotary function,it’s do not need extra pipe line,it can be connect to the pipe line of bucket cylinders.
-if have rotary function,need two kits extra auxiliary pipe line,we can prepare for you.

Hydraulic Clamshell Bucket For Excavator Specification:

Model Width(mm) Self weight(kg) Cylinder No.(pcs) Max Tilt degree(℃) Excavator tonnage(ton)
QXD50 1016(40”) 340 2 +/-45 4~7
QXD100 1270(50”) 580 2 +/-45 8~10
QXD120 1626(64”) 740 2 +/-45 11~16
QXD200 1778(70”) 920 2 +/-45 17~20
QXD250 1830(72”) 1120 2 +/-45 21~24

Above parameter is our non-rotary standard design,rotary function is selectable.
If have special design or requirements,we also can prepare for you.

Our advantages:


1. Side plate and tooth plate of the excavator clamshell bucket is NM400 steel,very wearable.

2. Rotary or Non-rotary is selectable

3. Bucket size,height,weight,bucket open,shape can design according to your projects' requirements.

Hydraulic Clamshell Bucket For Excavator Application:

2 Cylinders 1200L Excavator Spare Parts Excavator Attachments Excavator Hydraulic Clamshell Bucket2 Cylinders 1200L Excavator Spare Parts Excavator Attachments Excavator Hydraulic Clamshell Bucket2 Cylinders 1200L Excavator Spare Parts Excavator Attachments Excavator Hydraulic Clamshell Bucket

2 Cylinders 1200L Excavator Spare Parts Excavator Attachments Excavator Hydraulic Clamshell Bucket
