116-3526/40E30-701A Carter Excavator E320B Proportional Solenoid Valve

product details:

• Solenoid valve structure: (coil, magnet, ejector)

When the coil is connected to the current, the magnetism is generated, and the magnet attracts each other, and the magnet will pull the ejector rod. When the power is turned off, the magnet and the ejector rod are reset, so that the solenoid valve completes the work process

• The principle of distributed direct acting solenoid valve

It is a combination of direct action and pilot type. When there is no pressure difference between the inlet and the outlet, after the power is turned on, the electromagnetic force directly lifts the pilot small valve and the main valve closing piece up in turn, and the valve opens. When the inlet and outlet reach the starting pressure difference, after the power is turned on, the electromagnetic force pilots the small valve, the pressure in the lower chamber of the main valve rises, and the pressure in the upper chamber drops, so as to use the pressure difference to push the main valve upwards; when the power is off, the pilot valve uses a spring Force or medium pressure pushes the closing member, moving down, closing the valve

Features: It can also act safely under zero pressure difference or vacuum high pressure, but the power is large and must be installed horizontally

Solenoid valves are generally used in hydraulic systems to close and open oil circuits.
In fact, according to the temperature and pressure of the flowing medium, for example, the pipeline has pressure and the self-flow state has no pressure. The working principle of the solenoid valve is different

• As of today, we offer a wide range of solenoid valves:

1. Hydraulic pump proportional solenoid valve
2. Rotary Solenoid Valve
3. Pilot solenoid valve
4. lock solenoid valve
5. High pressure oil pump SCU solenoid valve
6. Main pump solenoid valve
7. High-speed solenoid valve
8. Distributor solenoid valve
9. Solenoid valve group
10. EGR solenoid valve assembly

Other models of excavators related solenoid valve models:

Shipping/Warehouse:

We offer accessories from the following brands:

Note:We are a professional manufacturer of electrical components.
Each of our parts will be tested more than 10 times from the factory to the sale to check whether the parts are normal, and then provided to customers, to ensure that we provide you with the best quality and assured products
