300x52.5Nx98 Undercarriage Rubber Rrack For Excavator Construction Machinery
300x52.5Nx98 Undercarriage Rubber Rrack For Excavator Construction Machinery
300x52.5Nx98 Undercarriage Rubber Rrack For Excavator Construction Machinery
300x52.5Nx98 Undercarriage Rubber Rrack For Excavator Construction Machinery
300x52.5Nx98 Undercarriage Rubber Rrack For Excavator Construction Machinery
300x52.5Nx98 Undercarriage Rubber Rrack For Excavator Construction Machinery
300x52.5Nx98 Undercarriage Rubber Rrack For Excavator Construction Machinery
300x52.5Nx98 Undercarriage Rubber Rrack For Excavator Construction Machinery
Specifications
Brand Name :
huilian
Model Number :
300x52.5Nx98
CertifiCATEEEEion :
ISO9001
Place of Origin :
China
MOQ :
1 Pieces
Price :
Competitive
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000 PCS per month
Delivery Time :
1-7days
Packaging Details :
Wooden Pallet
Product Name :
Excavator Rubber Track
Size :
Various size available
Material :
Natrual rubber
Quality :
OEM Standard
AppiCATEEEEion :
Excavator
Type :
Excavator Undercarriage part
Color :
Black
Description

Our Rubber Track Advantages

1. High speed
2. Low noise
3. Less vibration
4. Superior traction
5.Light machinery weight
6.Less damage to the ground surface
7.Low pressure to the ground surface
8.Easy to change

300x52.5Nx98 New Excavator Undercarriage Rubber Rrack for Excavator Construction Machinery

Part Name Excavator Rubber Track
Quality OEM High-Quality
AppliCATEEEEEEEEion Excavator
Color Black
Packing Standard Wooden cx packing or as customized.
Payment Terms T/T, Online trade assurance order (CC. VISA, T.T) paypal and Western Union
MOQ 1PC

Now we can produce the following size of rubber tracks:

NO. SpecifiCATEEEEEEEEion Links NO. SpecifiCATEEEEEEEEion Links
1 150*72 30-37 23 300*109W 34-46
2 180*60 30-48 24 320*54 70-92
3 180*72 31-42 25 320*84 48-63
4 200*72 33-47 26 320*86 48-63
5 230*48 60-82 27 320*90 47-63
6 230*72 31-64 28 320*100 37-62
7 250*72NM 52-57 29 320*100NM 41-54
8 230*96 30-41 30 320*106 37-46
9 230*96NM 40-50 31 350*52.5 78-106
10 230*101 30-42 32 350*56 70-86
11 250*72 43-60 33 350*56R 70-84
12 260*96 36-44 34 350*109 40-50
13 260*109 35-46 35 350*75.5 72-82
14 280*72 56-67 36 Y370*107 36-44
15 280*106 35-40 37 370*107K 38-41
16 300*52.5N 68-98 38 400*72.5A(N) 68-82
17 300*52.5W 68-92 39 400*72.5B(W) 68-82
18 300*52.5K 68-92 40 Y400*72.5 68-82
19 300*55 70-86 41 400*72.5R 68-82
20 300*55.5 72-84 42 K400*72.5 68-82
21 K300*109 34-46 43 400*75.5 74-82
22 300*109N 34-46 44 400*107 35-47

We can provide following excavator parts

Engine Assembly Final Drive Assy Hydraulic Pump Gear Pump
Swing Motor Travel Motor Fan Motor Electrical Parts
Swing Gearbox Travel Gearbox Relief Valve Distribution Valve
Available Engine Parts Radiator Main Valve Belt
Liner Kit Piston Piston Ring Engine Bearing
Cylinder Block Gasket Kit Gasket Head Crankshaft
Valve Valve Seat Valve Guide Nozzle
Bearing Accelerator Motor Transmitter Pressure Switch
Flameout Solenoid Monitor Fan Cooling Oil Filter

300x52.5Nx98 Undercarriage Rubber Rrack For Excavator Construction Machinery

Product Parameter

Width*pitch(mm) No. of links A B C D E Pattern Guide rail
100*72 28-83 23 64.5 28 28 15 Af1 A1
120*56 22-56 20 50 24 30 15 AL A1
130*72 28-53 23 64.5 28 28 15 AF1 A1
150*60 28-49 22 64 22.5 24.5 15 AC A1
150*72 29-40 23 64 23 23 15 AC A2
170*60 30-40 19 57 22 22 13 CE A1
180*60 30-40 23.5 64 21 21.5 15 AM A1
180*72 30-58 25 68 29 29 15 BK A2
180*72K 30-37 20 61 22 19.5 17 BB1 B2
B180*72K 34-51 29 66 30 29 15 BE A2
B180*72A 30-51 23 63 29 22 10 BE A2
H180*72 30*50 23 64 27 26 17 BK A2
190*60 30-40 23.5 64 21 21.5 14 AM A1
190*72 34-39 21 88 27.5 26.5 15 BF A2
200*72 34-47 23 76 28.5 26.5 18 BB1 A2
200*72K 37-47 21 69 29.5 29 18 BM A2
230*48 60-84 24 72 24 25 21 B1 B1
230*48K 60-84 24 66 21 20 19 B1 B1
230*72 42-56 24 62 30 26 18 AF1 A2
230*72K 42-56 20 69 29.5 28 16 BDA2

We Can Provide More Size Excavator Rubber Track

Width*pitch Link Rubber Track Size
130*72 29-40 180*60 230*48k
150*30 32-40 180*72 230*67
150*72 29-40 190*72 230*72
170*60 30-40 200*64 230*88
250*47 84 200*72 230*96
350*106 39-43 230*101 250*47
230*72 42-56 230*48 260*96
230*96 750*150 280*72
230*101 800*125 280*106
250*48.5K ...... .....
