Specifications
Brand Name :
Zhonghe Machinery
Model Number :
CLB0024
Certification :
ISO9001,ISO CE
Place of Origin :
China
MOQ :
1 set / piece
Price :
USD $6000- $34000/sets
Payment Terms :
T/T, L/C
Supply Ability :
800 sets
Delivery Time :
20-30/works
Packaging Details :
bubble / wooden cases
Material :
Q355B, Q690D, or others as you request
Length :
11-25m
Apply to :
20-85ton excavator
Warranty :
6 months
Working condition :
demolate buildings
Condition :
new
Color :
as customer requires
Application :
Mining / Construction,mining,building demolition and sepcial engineering,rock,for excavators
Type :
High Reach Demolition Boom
Oem :
Available
After-sales service provided :
Online support,Video technical support
Technique :
Advanced Techniques
Oem/odm :
acceptable
Description

High-efficiency piling arm Excavator foundation piling Vibratory pile driver for excavators

OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm

Product Description-----Excavator Pile driving Boom Arm

What is an excavator piling arm?

An Excavator Pile Driving Arm is a hydraulic device that attaches to an excavator, allowing it to install piles deep into the earth. This equipment is vital for ensuring stable foundations in civil engineering and construction applications.

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm

Advantages of excavator piling arm:

1. The design of the piling arm includes thicker upper and lower plates, reinforced internally in a double-layer structure. Stress points utilize segmented thickened plates, contributing to a longer lifespan of the arm.

  • 2. Achieving an opening angle of 160 degrees with the arm and 88 degrees at the base enhances both drilling power and efficiency, making operations more effective.
  • 3. The welding followed by drilling process on the piling arm ensures high precision, extending its longevity to match that of original equipment.

OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm

Some common size references

Excavator
(ton)
Total Length
(mm)
Boom
(mm)
 Arm(mm)

Pilling Height

(mm)
Counterweight
(ton)
30-36 13800 10000 3800 15400 3T
30-36 15000 10500 4500 17100 5T
40-45 15800 11000 4800 17900 3T
40-45 16800 11500 5300 18500 5T-6T
45-50 19000 12500 6500 21000 6T-7T

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Product Detail Display

OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm
OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm
OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Telescopic Boom Arm Engineering Case
OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm
OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm

The pile driving arm is suitable for the following working conditions:

  1. Earthquake-Prone Regions: Provides additional stability for structures in seismically active areas by ensuring deeper and more secure foundation support.
  2. Temporary and Permanent Installations: Effective for both temporary piling for support and permanent foundations in construction projects.
  3. Heavy Equipment Operations: Works well in conjunction with other heavy machinery, enhancing efficiency in large-scale construction operations..
  4. Eco-Sensitive Areas: Designed to minimize disturbance to surrounding environments, making it suitable for projects in sensitive ecological zones.
  5. Tunnel and Underground Work: Useful in constructing foundation piles for tunnel entrances or underground structures where traditional methods may be impractical.
  6. High Load Bearing Requirements: Capable of handling projects that require significant load-bearing capabilities, such as high-rise buildings or industrial facilities.
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm

About Hydraulic Vibratory Pile Driving Hammer

1. Some engineering applications:

Municipal sewage pipeline laying, land reclamation, bridge cofferdam, building foundation, high-speed rail foundation treatment, highway soft foundation treatment, wharf engineering, deep foundation pit support, etc.

2. The hydraulic vibratory hammer consists of four main components:
arm assembly, frame assembly, shell assembly, clamp assembly.
Mainly used for piling, such as driving reinforced concrete piles and steel plate U-shaped piles into the ground to reinforce the foundation, and then support the structure or fix the building.

OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Related Product Recommendation
OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver ArmOEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm
excavator long reach boom sliding boom/telescopic boom
OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver ArmOEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm
two-section telescopic boom two-section demolition boom
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

High precision machine of Zhonghe Machinery Manufacturers

OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm

Large Floor-Standing Double-Sided Boring and Milling Lathe:

  • Improved Accuracy and Consistency: The double-sided boring and milling lathe enhances the precision and uniformity of operations, ensuring consistent results.
  • Post-Welding Processing: After the welding process, the machine performs overall boring, ensuring the parallelism and perpendicularity of shaft holes.
  • Primary Applications: Primarily used for post-weld boring of the boom, small arm, and bucket, ensuring the accuracy and proper alignment of the boom.
  • Simultaneous Boring on Both Sides: The lathe performs boring on both sides at the same time, guaranteeing identical precision and consistency on both sides.

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

About Zhonghe Machinery Company Profile:

OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm

Kaiping Zhonghe Machinery Manufacturing Co., Ltd.

Established in 2018, Kaiping Zhonghe Machinery Manufacturing Co., Ltd. combines manufacturing with trading expertise. Our focus lies in customizing excavator booms and attachments, such as long arms and demolition tools, successfully marketed in over 60 countries.

Our key advantages are:

  • Approximately 18,000 square meters of operational space.
  • A skilled workforce of 120 personnel.
  • State-of-the-art equipment, including multiple milling and CNC machines.
  • A comprehensive custom production line for tailored solutions.
  • Efficient lead times of 7 to 25 days.
  • We produce 600 sets of excavator booms annually. Our principles emphasize "Quality, Sincerity, and Customer Satisfaction," inviting global cooperation.

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

CE certification & Utility model patent certificates

OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm

Our products have been exported to over 60 countries, utilizing various transportation methods such as sea, land, and air freight. For packaging, we use either wooden crates or stretch film to secure the products. Before shipment, the goods are carefully packaged and then loaded into containers to ensure their safety during transit.

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Packaging & Shipping

OEM 20-85ton Excavator Pile Driving Arm , Hydraulic Vibratory Pile Driver Arm

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

FAQ(Some frequently asked questions):

Q: Are you a manufacturer?

A: Zhonghe machinery offered a wide range of attachment parts for excavators and dozers. Such as long reach arm, demolition arm, telescopic arm, standard bucket, rock bucket, cleaning bucket, tilting bucket, etc. We know that the perfect combination of high-quality cast steel products and a moderate price is the key to the success.

Q: What material is the excavator demolition boom made of?
A: Shaogang Q355B, Shaogang's material has the advantages of good toughness, high welding performance, and not easy to crack. Q355B has good welding performance and can be processed at room temperature. The standard arm material of the host manufacturer is also Q355B, which is easier to purchase on the market and the subsequent maintenance cost is also simple. If the customer's working conditions are bad, we will also use Q690 material, the long arm will be made lighter and more efficient

Q: Why choose Zhonghe over other companies?

A: We offer a highly skilled production and design team that delivers high-quality, customized solutions tailored to each customer’s needs. Our commitment to precision and customer service has earned us a strong reputation in China, with annual sales consistently ranking among the top in the industry.

Q: What are your terms of payment?

A: We prefer T/T (50/50) payment terms, and for trial orders, we recommend using Ali Credit Insurance for added security.
