723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6
Specifications
Brand Name :
HQPA/OEM
Model Number :
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit
Certification :
ISO9001
Place of Origin :
CHINA(MAINLAND)
MOQ :
Negotiable
Price :
negotiation
Payment Terms :
Western Union, L/C, T/T, MoneyGram, D/A, D/P
Supply Ability :
500 Sets per Week
Delivery Time :
3-5 days after payment received(public holiday excluded)
Packaging Details :
PP bag inside, carton box outside
Product :
723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit
Part Number :
723-47-10200KT 723-47-10201KT 723-47-10600KT 723-47-10200 723-47-10201 723-47-10600 7234710200KT 7234710201KT 7234710600KT 7234710200 7234710201 7234710600 Hydraulic Main Control Valve Assy
Fit for model :
Komatsu PC200-6 PC230-6
Group :
Main Control Valve Seal Kit / Control Valve Seal Kit
Loading Port :
HUAGNPU,China (Mainland)
Packing :
Neutral packing / HQPA packing
Description

723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit for PC230-6
1.Product Description:

The travel motor provides the power that the final drive transforms into torque. Then torque is transferred to the sprocket, which turns the wheel or track.
The power comes from the hydraulic system.
When you find the travel lose power, there might be because the oil leakage caused to the travel motor.
In other words, the travel motor seal kit prevents oil from leaking and maintains power.


2.General Product Information:

723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit for PC230-6
Brand Name HQPA/OEM
Product Name 723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit for Komatsu PC200-6 PC230-6
Product style Main Control Valve Seal Kit / Control Valve Seal Kit
Part No. 723-47-10200KT 723-47-10201KT 723-47-10600KT 723-47-10200 723-47-10201 723-47-10600 7234710200KT 7234710201KT 7234710600KT 7234710200 7234710201 7234710600 Hydraulic Main Control Valve Assy
Related parts: Boom Cylinder Seal Kit / Arm Cylinder Seal Kit / Swing Motor Seal Kit / Travel Motor Seal Kit / Main Pump Seal Kit / Pilot Pump Seal Kit / Regulator Valve Seal Kit / Main Control Valve Seal Kit
Application Komatsu PC200-6 PC200-6S PC200LC-6 PC200LC-6S PC210-6 PC210LC-6G PC210-6G PC210LC-6 PC220-6 PC220LC-6 PC230LC-6 PC230-6
MOQ 1 PC
Condition 100% New
Package Inner-Plastic Bag; Outer -Standard Carton Box.
Payment Western Union, L/C, T/T, MoneyGram, D/A, D/P etc.
Departure ports Huangpu(Guangzhou), China (Mainland)
Delivery time 3-5 days after payment received(public holiday excluded)
Place of origin China (Mainland)
Application Excavators, heavy machinery, mining, earth-moving, construction machinery, digger, car, truck.

3. Fit Model

Part Number: 723-47-10200 723-47-10201 723-47-10600
Group: Main Control Valve Seal Kit
Fit for model: Komatsu PC200-6 PC200-6S PC200LC-6 PC200LC-6S PC210-6 PC210LC-6G PC210-6G PC210LC-6 PC220-6 PC220LC-6 PC230LC-6 PC230-6

4.Related spare parts:

723-47-10200 723-47-10201 723-47-10600 Main Control Valve Seal Kit For PC230-6

Part No Parts name Part No Parts name
723-47-10201 VALVE ASS'Y,1A SV LESS 723-47-10200 VALVE ASS'Y,1A SV LESS
207-62-33920 ELBOW 07002-01423 O-RING
21T-62-29960 TEE 20Y-62-23541 ELBOW
20Y-60-22260 VALVE ASS'Y 20Y-60-22270 POPPET
701-20-61230 SPRING 20Y-60-22230 NIPPLE
07002-11423 O-RING 20Y-62-22160 ADAPTER
723-47-10600 VALVE ASS'Y 723-47-10201 VALVE ASS'Y
723-47-10200 VALVE ASS'Y 723-40-70100 VALVE ASS'Y
723-40-80102 VALVE ASS'Y 723-40-80101 VALVE ASS'Y
723-40-80100 VALVE ASS'Y 723-40-66100 VALVE ASS'Y
723-40-66200 VALVE ASS'Y 07000-12012 O-RING
07000-12015 O-RING 07000-12018 O-RING
07000-12021 O-RING 07000-13025 O-RING
07000-13028 O-RING 07000-13032 O-RING
07000-03040 O-RING 01010-61490 BOLT
01010-61460 BOLT 01643-31445 WASHER
01010-81060 BOLT 01643-31032 WASHER
01252-61050 BOLT 01643-51032 WASHER
01011-61455 BOLT 723-46-15130 PLUG
07002-10823 O-RING 708-7T-16460 BALL
723-46-15120 RETAINER 723-46-14110 SPRING
723-46-15111 CASE 07430-71380 O-RING
01252-30820 BOLT 07000-11009 O-RING
07000-12021 O-RING 07000-12015 O-RING
07000-12018 O-RING 07000-13032 O-RING
07000-03040 O-RING 723-46-41110 VALVE
723-40-66300 VALVE ASS'Y 01252-60845 BOLT
01643-50823 WASHER 723-46-40500 VALVE ASS'Y
723-46-40100 VALVE ASS'Y 709-74-91510 PLUG
709-25-11390 O-RING 07001-01009 RING
700-93-11320 O-RING 723-46-41950 RING
07002-13634 O-RING 723-46-40500 VALVE ASS'Y
723-46-15130 PLUG 723-46-15140 PLUG
07002-10823 O-RING 708-7T-16460 BALL
723-46-15120 RETAINER 723-46-14110 SPRING
723-46-14161 SPRING 723-46-14170 SPRING
723-46-14131 SPRING 723-46-15250 SHIM
723-46-15110 CASE 07430-71380 O-RING
01252-30820 BOLT 723-46-15150 VALVE
723-46-14150 SPRING 723-46-41110 VALVE
723-46-41120 VALVE 723-46-15410 CASE
723-46-15530 PISTON 723-46-15520 PISTON
723-46-15420 RETAINER 723-46-15450 PLUG
07002-03034 O-RING 723-46-15440 SPRING
723-47-10600 VALVE ASS'Y 723-47-10201 VALVE ASS'Y
723-47-10200 VALVE ASS'Y 723-40-70100 VALVE ASS'Y
723-40-71160 SPRING 723-40-71140 PLUG
723-40-71150 PLATE 723-40-71170 SPRING
07040-11812 PLUG 07002-11823 O-RING
07002-13634 O-RING 07000-13032 O-RING
01252-30830 BOLT 723-40-80102 VALVE ASS'Y
723-40-80101 VALVE ASS'Y 723-40-80100 VALVE ASS'Y
723-46-15150 VALVE 723-46-14150 SPRING
723-46-15180 PLUG 07002-11823 O-RING
723-46-15190 VALVE 723-46-14140 SPRING
708-8E-16160 PLUG 07002-11023 O-RING
709-74-91860 PLUG 07002-12434 O-RING
723-46-40100 VALVE ASS'Y 723-46-46101 VALVE ASS'Y
723-46-40300 VALVE ASS'Y 723-46-40200 VALVE ASS'Y
723-46-40400 VALVE ASS'Y 723-46-41100 VALVE ASS'Y
723-46-45100 VALVE ASS'Y 723-46-15100 PLUG ASS'Y
723-40-50100 VALVE ASS'Y,RELIEF 723-40-50200 VALVE ASS'Y,RELIEF
723-40-56100 VALVE ASS'Y,UNLOAD 723-40-60100 VALVE ASS'Y
709-70-74302 VALVE ASS'Y,SUCTION AND SAFETY 709-70-74203 VALVE ASS'Y,SUCTION AND SAFETY
723-40-85100 VALVE ASS'Y,SUCTION 709-20-81201 VALVE ASS'Y,SUCTION
700-93-11320 O-RING 723-46-41950 RING
07002-13634 O-RING 723-46-40300 VALVE ASS'Y
723-46-40200 VALVE ASS'Y 723-46-40400 VALVE ASS'Y
723-46-41100 VALVE ASS'Y 723-46-15100 PLUG ASS'Y
07002-11423 O-RING 07000-11007 O-RING
07001-01007 RING,BACK-UP 723-46-46101 VALVE ASS'Y
723-46-45100 VALVE ASS'Y 07000-12014 O-RING
723-40-56350 RING 07000-12016 O-RING
723-60-22230 RING,BACK-UP 07002-12434 O-RING
723-40-60100 VALVE ASS'Y 07000-12020 O-RING
07001-02020 RING 709-25-11390 O-RING
700-80-61260 O-RING 700-80-61430 RING
07000-12021 O-RING 07001-02021 RING,BACK-UP
07002-13034 O-RING 07000-03032 O-RING
723-40-50200 VALVE ASS'Y,RELIEF 700-22-11410 O-RING
700-80-64220 RING 07002-02434 O-RING

5. Related models:

PC200-6 PC200-6S PC200LC-6 PC200LC-6S PC210-6
PC210LC-6G PC210-6G PC210LC-6 PC220-6 PC220LC-6
PC230LC-6 PC230-6 PC340NLC-6K PC27MR-2 PC300LC-3
D60A-6 D31E-20 PC130-5K PC14R-2 PC07-2
PC290LC-6K PC160LC-7 PC340NLC-7K PC600-8 PC160-6K
D75A-1 PW170ES-6K PC220-6 PC300LC-7 PC3000-1E
PC10N-7 PC308USLC-3E0 PC128UU-2 PC10MR-1-B PC650LC-7-M1
D85EX-15R PC200LC-6Z PC220-5 PC45-1 PC55MR-3
D65A-11D PC2000-8 PC200SC-7-M1 PC300LC-7E0 PC800-8E0
PC30MR-3(JPN) PC120-5 PC450LCD-7K PC200-8 PC50UU-2
PC10UU-3 PC220LC-7L PC07-1 D61EX-15E0 PC210LC-7K
D21A-8T PC200-2 DBD041-1 PC210LC-10 PC58UU-3
PC200LC-7 PC120SC-6 PC200SC-6 D21P-6 PC400-5
PC210-7-CA D39PX-22 PC380UU-3 PC75-1 D61EX-12
PW200-7K PC228US-3E0 PC35MR-1 D20QG-6 PC45MR-3
