703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5
Specifications
Brand Name :
HQPA/OEM
Model Number :
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit
Certification :
ISO9001
Place of Origin :
CHINA(MAINLAND)
MOQ :
Negotiable
Price :
negotiation
Payment Terms :
Western Union, L/C, T/T, MoneyGram, D/A, D/P
Supply Ability :
500 Sets per Week
Delivery Time :
3-5 days after payment received(public holiday excluded)
Packaging Details :
PP bag inside, carton box outside
Product :
703-08-33110KT 703-08-33110 Swivel Joint Seal Kit
Part Number :
703-08-33110KT 703-08-33110 7030833110KT 7030833110 Swivel Joint Assy
Fit for model :
Excavator Komatsu PC100-5 PC120-5
Group :
Center Joint Seal Kit / Swivel Joint Seal Kit
Loading Port :
HUAGNPU,China (Mainland)
Packing :
Neutral packing / HQPA packing
Description

703-08-33110KT 703-08-33110 Swivel Joint Seal Kit for Komatsu PC100-5 PC120-5
1.Product Description:

Swivel joint is used to be a channel for the hydraulic fluid going to the travel motor.

It has many other names, including rotary manifold, rotary union, center swivel, and center joint.

It's an important part of the machine.

If there is oil leak in the swivel joint, the travel motor will lose power.

So when the travel motor acts without power, you should take it into consideration too that whether it‘s the problem of swivel joint, and to change swivel join seal kits.


2.General Product Information:

703-08-33110KT 703-08-33110 Swivel Joint Seal Kit for Komatsu PC100-5 PC120-5
Brand Name HQPA/OEM
Product Name 703-08-33110KT 703-08-33110 Swivel Joint Seal Kit for Komatsu PC100-5 PC120-5
Product style Swivel Joint Seal Kit / Joint Seal Kit
Part No. 703-08-33110KT 703-08-33110 7030833110KT 7030833110 Swivel Joint Assy
Related parts: Boom Cylinder Seal Kit / Arm Cylinder Seal Kit / Swing Motor Seal Kit / Travel Motor Seal Kit / Main Pump Seal Kit / Pilot Pump Seal Kit / Regulator Valve Seal Kit / Main Control Valve Seal Kit
Application Komatsu PC100-5Z PC100-5 PC100-5C PC100-5S PC100L-5 PC120-5Z PC120-5 PC120-5X PC120-5M PC120-5S PC120-5C PC130-5 PC130-5S PC120-5K PC130-5K PC150HD-5K PC150NHD-5K
MOQ 1 PC
Condition 100% New
Package Inner-Plastic Bag; Outer -Standard Carton Box.
Payment Western Union, L/C, T/T, MoneyGram, D/A, D/P etc.
Departure ports Huangpu(Guangzhou), China (Mainland)
Delivery time 3-5 days after payment received(public holiday excluded)
Place of origin China (Mainland)
Application Excavators, heavy machinery, mining, earth-moving, construction machinery, digger, car, truck.

3. Fit Model

Part Number: 703-08-33110KT 703-08-33110
Group: Swivel Joint Seal Kit
Fit for model: Komatsu PC100-5Z PC100-5 PC100-5C PC100-5S PC100L-5 PC120-5Z PC120-5 PC120-5X PC120-5M PC120-5S PC120-5C PC130-5 PC130-5S PC120-5K PC130-5K PC150HD-5K PC150NHD-5K

4.Related parts

703-08-33110KT 703-08-33110 Swivel Joint Seal Kit For Komatsu PC100-5 PC120-5

Part No Parts name Part No Parts name
703-08-33110 SWIVEL JOINT ASS'Y 703-08-91730 ROTOR
703-08-95611 SEAL 703-08-96510 SEAL,OIL
07000-02105 O-RING 01010-50835 BOLT
01643-30823 WASHER 203-60-56702 TRAVEL MOTOR ASS'Y
203-60-56701 TRAVEL MOTOR ASS'Y TZ203B210101-A FLANGE KIT,REAR
TZMB700-070 PLUG TZGM1-4 PLUG
TZGM1-8 PLUG TZMB700-050 PLUG
TZ850A0006-00 PLATE, NAME 04260-00793 BALL
TZ210A7105-00 PISTON KIT,(9 PIECES) TZ200B2004-00 BLOCK,CYLINDER
TZ200B200301-C PLATE,SWASH TZ200B2032-01 PLATE
TZ200B2032-00 PLATE,THRUST TZ200B2007-01 PLATE
TZ231F2012-00 PISTON TZ100A2013-00 SPRING
07000-15145 O-RING TZ231F2023-00 RING,BACK-UP
07000-15170 O-RING TZSUN-2BG170 RING,BACK-UP
TZ200B2002-01 SHAFT TZJB1501-26 BALL
06000-06207 BEARING TZTCN-32-52-11 SEAL,OIL
TZ210A2009-00 PLATE,TIMING TZJB1354-5-12 PIN
06000-06204 BEARING TZ430F2019-00 VALVE
TZ100A2020-00 SPRING 07000-11009 O-RING
TZ100A2018-00 SEAT,VALVE TZ100A2022-00 RING
TZ200B2073-00 VALVE TZ300B2043-01 SPRING
TZ300B2039-00 STOPPER TZ300B2042-00 RING
TZ200B2085-00 SPRING 203-60-56702 TRAVEL MOTOR ASS'Y
203-60-56701 TRAVEL MOTOR ASS'Y TZ203B2107-01 BODY KIT
TZ203B2107-00 BODY KIT TZ150F2075-00 STOPPER
TZ150F2077-00 SPRING TZ150F2064-01 SPRING
TZ203B2062-00 PLUG 07000-13032 O-RING
07000-11006 O-RING 07000-12020 O-RING
01252-30860 BOLT 01252-30855 BOLT
TZSW-M8 WASHER TZ100A2052-00 STOPPER
07002-02034 O-RING TZJB1354-10-28 PIN
01252-31440 BOLT 203-60-56702 TRAVEL MOTOR ASS'Y
203-60-56701 TRAVEL MOTOR ASS'Y TZ240B1001-00 HUB
TZ200B1001-00 HUB TZ200B1102-03 SPINDLE KIT
07000-15280 O-RING TZ200B1021-00 BEARING
TZ200B1104-02 RV GEAR ASS'Y TZ200B1204-01 RV GEAR KIT
TZ200B1009-01 SHAFT,CRANK TZ200B1022-00 BEARING
TZ200B1023-00 BEARING TZ150A1020-00 SNAP RING KIT,(12 KINDS)
TZ700C1016-00 RING TZ200B1008-00 COVER
TZGM1-2 PLUG TZARP568-378-9 O-RING
01010-31245 BOLT TZSW-M12 WASHER
07000-11008 O-RING TZJW1516-G41-9 O-RING
TZJB2808-4-14 PIN TZ220B9000-00 SERVICE KIT
TZ205B9000-00 SERVICE KIT 07000-15145 O-RING
TZ231F2030-00 RING,BACK-UP 07000-15170 O-RING
TZSUN-2BG170 RING,BACK-UP TZTCN-32-52-11 SEAL,OIL
07000-11009 O-RING 07000-13032 O-RING
07000-11006 O-RING 07000-12020 O-RING

5. Relates:

We have important business in the overseas market due to our high quality and reasonable prices.

Also, we can supply all kinds of excavator spare parts according to customers’ requirements!

All the picture is just for your reference.

We can provide service according to the client's requirements!

Welcome to contact us, we can provide high quality and the best price!
