Specifications
Brand Name :
HUITONG
Model Number :
Excavator long boom
CertifiPCion :
ISO9001
Place of Origin :
CHINA
MOQ :
1 set
Price :
$500-2000/PCS
Payment Terms :
D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 SETS/months
Delivery Time :
6-8 days
Condition :
100%new
Warranty :
1 Year
After-sales service provided :
Online support,Video technical support
Operating weight :
24300kg,12200kg,9000kg,23100kgs,22ton
Color :
Customer's Request
Material :
Q345B+Q460D
Type :
Standard or Enhanced Boom Arm
Description

Excavator For Hitachi Zx470 Long Reach Boom Arm Excavator Parts Tata Hitachi Long Boom

Advantages

With our expertise in designing and manufacturing long reach booms, you can now maximize your ROI (Return on Investment) on your existing fleet of excavators. Hundreds of customers have realized the value of long reach attachments where standard booms fail to get the necessary job done. Our long reach boom can help you to achieve 50% more digging depth and forward reach over a standard boom, saving you valuable cost and time, and maximizing your bottom line. Only structural grade tensile steel is used in our boom and stick construction, and we design it with varying grades of tensile steel depending on the nature of the appliPCion. We supply long reach front packages for a wide range of excavator models, ranging from 10 -200 metric tons (22,000 – 488,400 lbs) operating weight.

Welding is done by robotic welding machine to ensure the highest attainable quality and consistency. Product design are accomplished by utilizing latest CAD software, simulated via advance Finite Element Analysis (FEA) tools, ensuring optimum design integrity.

Q460D Tata Zx470 Long Reach Excavator Booms Operating Weight 9000kgQ460D Tata Zx470 Long Reach Excavator Booms Operating Weight 9000kg

Products Description
Excavator Operating Weight Length

A


Max. Reach

B


Max. Depth

C


Max. Height

D


Boom Height

 Approximate Bucket Capacity
m ft m ft m ft m ft m ft m3 Yard3
12-14 ton 12.0 39′ 12.00 39′ 4″ 8.30 27′ 2″ 10.50 34′ 5″ 2.10 6′ 11″ 0.4 0.52
(26,400-30,800 lb) 13.0 43′ 13.00 42′ 8″ 9.00 29′ 6″ 10.90 35′ 9″ 2.10 6′ 11″ 0.3 0.39
15-16 ton 14.0 46′ 14.00 45′ 11″ 10.70 35′ 0″ 11.80 38′ 8″ 2.30 7′ 6″ 0.4 0.52
(33,000-35,200)
20-22 ton 15.5 50′ 15.50 50′ 10″ 11.46 37′ 7″ 13.78 45′ 3″ 2.50 8′ 3″ 0.50 0.66
(44,000-48,400 lb) 16.5 54′ 16.50 54′ 2″ 12.16 39′ 11″ 14.40 47′ 3″ 2.50 8′ 3″ 0.40 0.52
23-27 ton 17.0 56′ 17.00 59′ 9″ 12.80 41′ 11″ 14.95 49′ 0″ 2.70 8′ 11″ 0.50 0.66
(50,600-55,000 lb) 18.0 59′ 18.00 59′ 0″ 14.00 45′ 11″ 15.85 51′ 9″ 2.70 8′ 11″ 0.40 0.52
28-30 ton 18.0 59′ 18.00 59′ 0″ 13.80 45′ 1″ 15.20 49′ 10″ 3.10 10′ 2″ 0.60 0.79
(61,600-66,000 lb) 19.0 62′ 19.00 62′ 3″ 14.00 45′ 11″ 15.50 50′ 10″ 3.10 10′ 2″ 0.50 0.66
33-35 ton 18.5 60′ 18.50 60′ 5″ 14.50 47′ 6″ 15.10 49′ 6″ 3.40 11’0″ 0.70 0.92
(72,600-77,000 lb) 20.0 65′ 20.00 65′ 6″ 16.00 52′ 6″ 15.60 51′ 3″ 3.40 11’0″ 0.60 0.79
40-44 ton 21.0 68′ 21.00 68′ 10″ 15.30 50′ 2″ 15.58 49′ 3″ 3.70 12′ 2″ 0.80 1.05
(88,000-96,800 lb) 22.0 72′ 22.00 72′ 2″ 16.25 53′ 4″ 15.92 52′ 3″ 3.70 12′ 2″ 0.70 0.92
45-55 ton 21.0 68′ 21.00 68′ 10″ 15.00 49′ 3″ 15.95 52′ 4″ 3.95 12′ 11″ 1.00 1.31
(99,000-121,000 lb) 22.0 72′ 22.00 72′ 2″ 15.80 51′ 10″ 16.05 52′ 8″ 3.95 12′ 11″ 0.90 1.18
60-65 ton 23.0 75′ 23.00 75′ 5″ 17.50 57′ 4″ 17.50 57′ 5″ 4.10 13′ 6″ 1.20 1.57
(132,000-143,000 lb)
70-75 ton 24.0 79′ 24.00 78′ 8″ 18.10 59′ 3″ 19.00 62′ 4″ 4.60 15′ 1″ 1.30 1.70
(154,000-165,000 lb)
80-90 ton 25.0 82′ 25.00 82′ 0″ 18.60 61′ 00″ 19.20 62′ 11″ 4.70 15′ 5″ 1.40 1.83
(176,000-198,000 lb)
100-110 ton 27.0 88′ 27.00 88′ 7″ 20.00 65′ 7″ 19.00 62′ 4″ 5.00 16′ 5″ 1.60 2.10
(220,000-242,000 lb) 28.0 92′ 28.00 91′ 9″ 21.00 68′ 10″ 20.00 65′ 7″ 5.00 16′ 5″ 1.40 1.83
120-130 ton 28.0 92′ 28.00 91′ 9″ 21.00 68′ 10″ 20.00 65′ 7″ 5.50 18′ 1″ 1.60 2.10
(264,000-286,000 lb) 29.0 95′ 29.00 95′ 1″ 22.00 72′ 2″ 20.50 67′ 3″ 5.50 18′ 1″ 1.40 1.83
