Specifications
Brand Name :
ZHONGMEI
Model Number :
ZM23
Certification :
CE，EPA，ISO，TUV
Place of Origin :
shandong
MOQ :
1 set
transport length :
3575mm
transport height :
2405mm
transport width :
990mm
track length :
1593mm
wheelbase :
1230mm
digging height :
3535mm
unloading height :
2445mm
Description

Introduction Of ZM23 2.3T Small Digger Hydraulic CE/EPA Compact Crawler Mini Excavator

The 2.3-ton mini excavator is ideal for a range of applications, including residential construction, landscaping, utility installations, and renovation projects. Its versatility and ease of operation make it a valuable asset for contractors, landscapers, and operators who require efficient and precise digging capabilities in confined spaces.

Whether it's digging trenches, excavating foundations, or completing site preparations, the 2.3-ton mini excavator provides the power, maneuverability, and reliability needed to tackle various tasks with ease.

Parameter Of ZM23 2.3T Small Digger Hydraulic CE/EPA Compact Crawler Mini Excavator

Dimensions
transport length 3575mm
transport height 2405mm
transport width 990mm
track length 1593mm
wheelbase 1230mm
The scope of work
digging height 3535mm
unloading height 2445mm
digging depth 2270mm
Maximum Vertical Digging Depth 1910mm
digging radius 3910mm
Maximum digging radius at ground level 3845mm
Bulldozer blade maximum lifting height 280mm
Maximum cutting depth of bulldozing blade 190mm
engine
model Kubota D902
form Three-cylinder direct injection
Displacement 0.898L
rated power 11.8KW/2300rpm
Hydraulic system
form load sensitive
Rated working flow 64.4L/min
walking system
Number of rollers 3x2
Walking speed 0~2.2~4.3km/h
traction 18KN
Gradeability 58%
Ground clearance 145mm
bucket
Bucket capacity 0.04m³
Bucket Digging Force 16KN
Stick Digging Force 9.5KN
Machine weight, slewing system
Total Weight 1800kg
Ground specific pressure 29KPa
Swing speed 9.5r/min
Oil capacity
fuel tank capacity 19L
cooling system 5.05L
engine oil volume 3.7L
Hydraulic tank 13.7L/21.4L

Photos Of ZM23 2.3T Small Digger Hydraulic CE/EPA Compact Crawler Mini Excavator

Mini Excavator Hydraulic Imported HydraulicTrack Rubber Track Backhoe ExcavatorsMini Excavator Hydraulic Imported HydraulicTrack Rubber Track Backhoe ExcavatorsMini Excavator Hydraulic Imported HydraulicTrack Rubber Track Backhoe Excavators

Mini Excavator Hydraulic Imported HydraulicTrack Rubber Track Backhoe Excavators

Mini Excavator Hydraulic Imported HydraulicTrack Rubber Track Backhoe ExcavatorsMini Excavator Hydraulic Imported HydraulicTrack Rubber Track Backhoe ExcavatorsMini Excavator Hydraulic Imported HydraulicTrack Rubber Track Backhoe Excavators
