Specifications
Brand Name :
ZHONGMEI
Model Number :
ZM30
Certification :
CE，EPA，ISO，TUV
Place of Origin :
shandong
MOQ :
1 set
Working weight :
2500 Kg
Bucket capacity :
0.1 m³
Engine power :
22.1 KW (National II)
Engine rated speed :
2200 r/min
Hydraulic system pressure :
16 MPa
Climbing degree :
30°
Total length (A) :
4200 mm
Total width (B) :
1300 mm
Total height (C) :
2300 mm
Description

Introduction Of NEW 3 ton Mini Excavator Hydraulic Small Micro Digger All Special Models Mini Crawler Excavators

Introducing our Small Excavator - the perfect solution for your digging needs. With a working weight of 2500 Kg and a compact design, this excavator is highly maneuverable, making it ideal for tight spaces. Its 0.1m³ bucket capacity ensures efficient digging, while the 22.1KW (National II) engine provides reliable power at a rated speed of 2200 r/min.

Equipped with a robust hydraulic system with a pressure of 16MPa, our excavator can handle tough tasks with ease. Its impressive climbing degree of 30° allows it to navigate challenging terrains effortlessly. The 23×10³ N/m² grounding pressure ensures stability during operation.

Parameter Of NEW 3 ton Mini Excavator Hydraulic Small Micro Digger All Special Models Mini Crawler Excavators

Parameter Value
Working weight 2500 Kg
Bucket capacity 0.1 m³
Engine power 22.1 KW (National II)
Engine rated speed 2200 r/min
Hydraulic system pressure 16 MPa
Climbing degree 30°
Grounding pressure 23×10³ N/m²
Traveling speed 2 Km/h
Max. traction force 11.5 KN
Platform rotation speed 10 r/min
Dimension
Total length (A) 4200 mm
Total width (B) 1300 mm
Total height (C) 2300 mm
Platform turning radius (D) 1250 mm
Track length (E) 1900 mm
Height above ground (F) 260 mm
Movable arm end height (G) 960 mm
Platform outer width (H) 1060 mm
Engine cover height (I) 1390 mm
Platform height above ground (J) 810 mm
Track width (K) 230 mm
Operating range
Max. digging height (A) 3200 mm
Max. unloading height (B) 2450 mm
Max. digging depth (C) 2350 mm
Max. digging radius (D) 4200 mm
Max. ground level digging distance (D1) 3100 mm
Max. digging height of digging radius (E) 3800 mm
Min. turning radius (F) 2300 mm
Max. bucket depth of bulldozing shovel (G) 150 mm
Max. lifting height of bulldozer (H) 210 mm

Photos Of NEW 3 ton Mini Excavator Hydraulic Small Micro Digger All Special Models Mini Crawler Excavators

NEW ZM30 3 ton Mini Excavator Hydraulic Small Micro DiggerNEW ZM30 3 ton Mini Excavator Hydraulic Small Micro DiggerNEW ZM30 3 ton Mini Excavator Hydraulic Small Micro Digger

NEW ZM30 3 ton Mini Excavator Hydraulic Small Micro DiggerNEW ZM30 3 ton Mini Excavator Hydraulic Small Micro DiggerNEW ZM30 3 ton Mini Excavator Hydraulic Small Micro DiggerNEW ZM30 3 ton Mini Excavator Hydraulic Small Micro Digger
