Specifications
Condition :
New
Brand Name :
LD
Year :
2023
Dimension(L*W*H) :
35m*5m*5m
Weight :
18 KG
Place of Origin :
China
Automatic Grade :
Automatic
Voltage :
380
Power :
180
Machinery Capacity :
400KGS/HOUR
Key Machines :
extruding and shaping
Product name :
hot melt glue stick production line
Applicable Industries :
Chemical Industry
After-sales Service Provided :
1 year
Material Feature :
Oil Resistant
Keyword :
eva sticker making machine
Usage :
for making hot melt glue sticker
Packaging Details :
STANDARD EXPORT WOODEN CASES
Supply Ability :
5 Set/Sets per Month
Price :
$380,000.00/sets 1-1 sets
MOQ :
1 set
Description

AUTOMATIC HOT MELT GLUE STICK MAKING PRODUCTION LINE

Process:

Put in raw materials→automatic feeding→mixing→spiral extrusion molding→cooling and shaping→automatic pulling→automatic cutting→finished product

1. The whole line composition:

1). Reactor 2 sets (capacity depends on the quantity required).

2). Extruding machine 1 set

3). Water basin 24meter

4). Cooling system (Refrigerator) 1 set

5). Cutting stick machine 1 set 4 heads

The other detail configuration can be designed as customer output requirements.


NO.

NAME

UNIT

QTY

DETAILS

1

1000L

Reactor

SET

1

Kettle body structure: flange open type

30kw motor, variable frequency speed regulation

Hard tooth surface reducer

Rack DJ83, mechanical seal 212-80

304 stainless steel shaft speed Φ65 -65 rpm

Inner barrel : 304 Stainless steel , Φ1000*1250*8mm

Outer barrel :A3 steel, Φ1200*1250*5mm

Upper and lower inner heads : 304 Stainless steel, Φ1000*8mm

Outer head : A3 steel, Φ1200*8mm

Heating rods 3kw*12 pieces (four-zone heating, automatic temperature control)

Stainless steel surface polishing treatment, carbon steel outer surface painting treatment

The power distribution cabinet contains contactors, start and stop buttons, frequency converters, etc.

The head is equipped with quick-opening manhole, stainless steel flange, sight glass, etc.

Note: Please refer to the drawing for the remaining details .

2

Filter

And delivery

SET

1

First-level filtration: bag filter 0.3 square meters (all contact materials are made of 304 stainless steel)

Viscosity pump: 4kw (frequency control) 100L thermal insulation storage tank

3

Oil circulation system

SET

1

1.5kw thermal oil pump, lower discharge pipeline, filtration, oil circulation
