Diamond Expanding Wire Mesh Metal Sheet Anodized 2m Width 6m Length
Diamond Expanding Wire Mesh Metal Sheet Anodized 2m Width 6m Length
Diamond Expanding Wire Mesh Metal Sheet Anodized 2m Width 6m Length
Diamond Expanding Wire Mesh Metal Sheet Anodized 2m Width 6m Length
Diamond Expanding Wire Mesh Metal Sheet Anodized 2m Width 6m Length
Diamond Expanding Wire Mesh Metal Sheet Anodized 2m Width 6m Length
Specifications
Brand Name :
Source Wire Mesh
Model Number :
Exaned Mesh
Certification :
ISO9001
Place of Origin :
Hebei,china
MOQ :
200M2
Price :
$2.15-$3.25/M2
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3000 Square Meter/Square Meters per Day 20000square meters/week
Delivery Time :
according to the customer's qty
Packaging Details :
1)in rolls: water-proof paper inside and plastic film outside 2)in sheets: on the pallet, water-proof paper and plastic film outside
Material :
Stainless Steel Wire, Galvanized Steel Wire, Aluminum sheet, Stainless Steel/Aluminum, galvanized plate
Application :
Protecting Mesh, Filters, Screen, Barbecue Wire Mesh, Fencing
Type :
Expanded Mesh
Wire diameter :
Requirement, 0.03-5mm, 0.5-8mm, 0.2mm-8mm, 0.1-10mm or Requirement
Surface treatment :
Hot Dipped Galvanized, Anodized, Powder coated, Galvanized, powder coating
Feature :
Liquid Filter, screen, Construction, Curtain, filtration
Color :
Silver, red, Black, white, yellow
Hole shape :
Diamond Hole, Square Hole, hexagonal, etc, round and hexgonal shape
Length :
1-30m,1-6m
Width :
0.5-2m, Customers' Requirement, 0.5m-2.5m
Thickness :
1-5mm, 1.5mm-6.0mm, 0.5-8mm
Short way of mesh :
2-40mm, 2mm-50mm
Sample :
free
Description

Gold Supplier air filters outer wire mesh expanded metal mesh

1) Material: Aluminum ,galvanized sheet, stainless steel wire mesh, copper mesh
2) Pattern: Opening in the shape of diamond, hexagonal or special shape.
3) Features: The expanded metal mesh is strong and durable, with pleasing appearance in its shapes.

4) Sizes: Long way of mesh: 3-100mm ;
Short way of mesh: 2-80mm;
Thickness: 0.3-5mm;

EXPENDED FLATTENED MESH
LWD(mm) SWD(mm) Strand Width Strand Gauge %Free Area Approx.Kg/m2
6.05 3.38 0.5 0.8 50 2.1
10.24 5.84 0.5 0.8 75 1.2
10.24 5.84 0.9 1.2 65 3.2
3.80 2.10 0.8 0.6 46 2.1
14.20 4.80 1.8 0.9 52 3.3
24.40 7.10 2.4 1.1 57 3.4
23.20 5.80 3.2 1.5 43 6.3
32.70 10.90 3.2 1.5 59 4
33.50 12.40 2.3 1.1 71 2.5
42.90 14.20 4.6 2.7 58 8.6
39.10 18.30 4.7 2.7 60 7.6
43.20 17.08 3.2 1.5 69 3.2
69.80 37.10 5.5 2.1 75 3.9
