Specifications
Brand Name :
ROSCHEN
Model Number :
For the size of button bits 6-25 mm
Certification :
ISO9001
Place of Origin :
Germany
MOQ :
1 set
Packaging Details :
wooden box
Description

Quarry Rock Drilling Button Bits Grinding Pin , Diamond button bits grinder 6mm - 25mm


Button bit grinder

Quick Details
Place of Origin: Germany Brand Name: ROSCHEN
Model Number: RS100 Shape: Cup-Shaped
Abrasive: Diamond Bonding Agent: Metal
Size: Various Size Application: Quarrying, Mining, Engineering
Size dia.: 7-20mm Usage: Sharpening the button bits
Bits Dia,: 6-25mm Color: Blue, Yellow, Green
Condition: New Shank: Normally 8mm or 9mm
Bits Shape: Hemispherical, Ballistic, Semi Ballistic, Paraboloid or Conical pins Equipment: Button bits grinder
Type: Grinding Pin 　 　


Packaging & Delivery:

Packaging Details: Wooden cases/cartons or according to your specific requirements FOR Hot Sales Quarry Rock Drilling Button Bits Diamond Grinding Pin
Delivery Detail: In stock or within 25days


Specifications

1 Button bit diamond grinding pin
2 Grind the button and steel both
3 For button size 6mm-25mm
4 Four models are vailable


Hot Sales Quarry Rock Drilling Button Bits Diamond Grinding Pin

Our factory specializing in producing diamond Button Bits grinding cups/ grinding pin. It's a perfect tool for grinding your broken/worn button bits, to prolong it's lifespan.


Standard AIR / WATER ways on grinding pin

Quarry Rock Drilling Button Bits Grinding Pin , Diamond button bits grinder 6mm - 25mm

1). Single-water way is suitable for all insert shapes and all types of grinding machines.

2). The 3-water ways are standard on all grinding pin larger than 14mm. Gives a better redressing result, longer life of the grinding pin.

Models & Details

We have different models:

8mm shank model,

9mm shank model,

internal hex drive model,

55-drive model.

Our grinding pin can be used for grinding 7mm-25mm button size. Other sizes available on request.

Except 55-drive model, the others model all can be used for grinding both the bit button and body steel in one operation.

The combination grinding pin benefits from a specially developed grinding material capable of grinding both carbide and steel at a regular and consistent rate.

For bit's button shape For bit's button size (mm)
spherical buttons ballistic buttons 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
bit's body steel removal 7-8 9-10 11-12 13-14 15-16 17-18 19-20

Available with a choice of Hemispherical, Ballistic Semi Ballistic, Paraboloid or Conical cups.



Quarry Rock Drilling Button Bits Grinding Pin , Diamond button bits grinder 6mm - 25mm
Quarry Rock Drilling Button Bits Grinding Pin , Diamond button bits grinder 6mm - 25mm
