Rock Drill Tools BWJ NWJ 2-5/8'' Wired Drill Pipe
Rock Drill Tools BWJ NWJ 2-5/8'' Wired Drill Pipe
Rock Drill Tools BWJ NWJ 2-5/8'' Wired Drill Pipe
Rock Drill Tools BWJ NWJ 2-5/8'' Wired Drill Pipe
Rock Drill Tools BWJ NWJ 2-5/8'' Wired Drill Pipe
Rock Drill Tools BWJ NWJ 2-5/8'' Wired Drill Pipe
Specifications
Brand Name :
ROSCHEN
Model Number :
2 3/8"
Certification :
ISO
Place of Origin :
Germany
MOQ :
Negotiable
Price :
Negotiable
Supply Ability :
1000 pcs
Packaging Details :
steel bundles
Name :
Wired Drill Pipe
Processing type :
Forging,Casting
Use :
Coal Mining
Material :
High Manganese Steel
Usage :
Rock Drill Tools
Color :
As picture
Description

Rock Drill Tools BWJ NWJ 2-5/8'' Wired Drill Pipe

Wired Drill Pipe Description:


Drill pipes that are used in applications such as DTH/ DTHR/ DR basically comprise of a steel pipe with a pin at one end and a box on the other. The job of the drill pipe is to transmit rotational torque and thrust from the drill rig rotary head to down hole drilling tools.

According to different application, different diameters of drill tubes are needed, basically, smaller DTH hammers need smaller DTH drill tubes, vice versa. Usually we are offering 50mm, 60mm, 76mm, 89mm, 95mm, 102mm, 114mm 127mm, 140mm, 159mm etc.

Usually the threads are standard API connections, like 2 3/8" API REG thread, 3 1/2" API REG thread or API IF thread, etc.
According to customers request, from1000mmto6000mmlength of pipe are available.

Wired Drill Pipe Features:


1. Thread oil should be used when screwing the drill rod and hammer knocking should be prohibited.
2. The drill rod stand should have buffer materials, like wood, rubber, and more. The contact between the threaded ends and iron tools should be forbidden.
3. During the relocation of drill rod, the thread protector should be screwed on the threaded parts so as to protect it from damages.


Wired Drill Pipe Technical Parameters:

J-Series Drill Rod Assembly Outside Diameter Threads Assembly Length Assembly Weight Assembly Part Number
Per Inch
AWJ 1-3/4-inch (35mm) 5-TPI 1-Foot (305mm) 3-Pounds (1.4 kg) 27014
AWJ 1-3/4-inch (35mm) 5-TPI 2-Foot (610mm) 6-Pounds (2.7 kg) 27015
AWJ 1-3/4-inch (35mm) 5-TPI 3-Foot (914mm) 11-Pounds (5 kg) 27016
AWJ 1-3/4-inch (35mm) 5-TPI 4-Foot (1.2m) 16-Pounds (7.3 kg) 27136
AWJ 1-3/4-inch (35mm) 5-TPI 5-Foot (1.5m) 20-Pounds (9.1 kg) 27017
AWJ 1-3/4-inch (35mm) 5-TPI 10-Foot (3.1m) 32-Pounds (14.5 kg) 27018
NWJ 2-5/8-inch (67mm) 5-TPI 1-Foot (305mm) 7-Pounds (3.2 kg) 27009
NWJ 2-5/8-inch (67mm) 5-TPI 2-Foot (610mm) 15-Pounds (6.8 kg) 27010
NWJ 2-5/8-inch (67mm) 5-TPI 3-Foot (914mm) 18-Pounds (8.2 kg) 27011
NWJ 2-5/8-inch (67mm) 5-TPI 5-Foot (1.5m) 30-Pounds (13.6 kg) 27012
NWJ 2-5/8-inch (67mm) 5-TPI 10-Foot (3.1m) 60-Pounds (27.2 kg) 27013


Wireline Series Drill Rods:

Specifications of Drill Rods
Size OD (mm) ID (mm)
WLA 44.7 37.3
WLB 55.7 46.1
WLN 70.0 60.2
WLH 89.0 78.0
WLP(PHD) 114.5 101.5
AW/AWJ/AWY 43.7 30.7
BW/BWJ/BWY 54.0 38.0
NW/NWY 66.8 51.0
HW 89.0 71.0
Φ42 42.0 30.0
Φ50 50.0 37.0
Φ60 60.0 48.0
Φ70 73.0 54.6
Φ90 89.0 69.0
S75 71.0 61.0


AW, BW, NW, AWJ, BWJ, NWJ, N3, N4 Series:

Size O.D. Rod Body I.D. Weight Threads per Inch Volume
in mm in mm lbs/10ft kg/3m gal/100ft L/100m
AW 1.75 44.5 1.25 31.8 44 19.6 3 6 75
BW 2.13 54 1.75 44.5 40 18.2 3 12.5 155
NW 2.63 66.7 2.25 57.1 51 23.3 3 20.7 257
AWJ 1.75 44.5 1.37 34.9 33 14.7 5 7.2 90
BWJ 2.13 54 1.75 44.5 40 18.2 5 11.8 146
NWJ 2.63 66.7 2.25 57.1 55 24.6 4 19.6 244
N3 2.38 60.45 1.13 28.7 N/A N/A 3 80.1 36.33
N4 2.13 54.1 1 25.4 N/A N/A 4 80.1 36.33

No Size Drill rod Thread type Raw material
OD mm ID mm
1 AWJ 44.5 34.1 DCDMA Standard 45MnMoB R780
AWY
2 BWJ 54 44.5
BWY
3 NWY 67 57
4 HW 89 77.8
5 Φ42 42 32 China GB standard R780
6 Φ50 50 39 R780
7 Φ60 60 48 R780

Wired Drill Pipe Pictures

Rock Drill Tools BWJ NWJ 2-5/8'' Wired Drill Pipe

Rock Drill Tools BWJ NWJ 2-5/8'' Wired Drill Pipe
