RC Drill Rods RC Drill Pipe 4 1/2 Inch Remet Thread For Atlas Copco Secoroc RC45 RC50 RC Hammer Drilling
RC Drill Rods RC Drill Pipe 4 1/2 Inch Remet Thread For Atlas Copco Secoroc RC45 RC50 RC Hammer Drilling
RC Drill Rods RC Drill Pipe 4 1/2 Inch Remet Thread For Atlas Copco Secoroc RC45 RC50 RC Hammer Drilling
RC Drill Rods RC Drill Pipe 4 1/2 Inch Remet Thread For Atlas Copco Secoroc RC45 RC50 RC Hammer Drilling
RC Drill Rods RC Drill Pipe 4 1/2 Inch Remet Thread For Atlas Copco Secoroc RC45 RC50 RC Hammer Drilling
RC Drill Rods RC Drill Pipe 4 1/2 Inch Remet Thread For Atlas Copco Secoroc RC45 RC50 RC Hammer Drilling
Specifications
Brand Name :
ROSCHEN
Model Number :
4 1/2 inch
Certification :
ISO
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiate
Supply Ability :
7000
Packaging Details :
Bundle
Usage :
Rock drilling,mining
Advantage :
competitive advantage products
Color :
Black or as per your demands
Wall thickness :
5-19mm
Shank :
h22*108mm and h25*159mm
Item name :
Oil Hardening Drill Rod
Description

RC Drill Rods RC Drill Pipe 4 1/2 Inch Remet Thread For Atlas Copco Secoroc RC45 RC50 RC Hammer Drilling

Introduction

DTH drill pipes play a significant role in all DTH drilling, regardless type of rock, hole depth or drill rig.

The key features of a high quality DTH tube are durability, accuracy and manageability.


RC Drilling Equipment

Specialist RC drilling equipment, reverse circulation drill pipe and RC drilling tools.


RC Drill Rods/Pipe

INLOK RC Drill Rods

Drill & Blast Rods and Subs

Spiral Stabilizer Subs

Blow Downs for RC Drilling

Adapters and Saver Subs

Air Core Drill Bits

Inner Tubes for RC Drilling

Wear Bends, Deflector Boxes

Inlet and Bearing Swivels

Head Wear & Hammer Tubes

Hose Tails, Knock-On Nuts

Reverse Circulation Drill Pipe

Tool Joint Spanner Flats
Rods available with or without spanner flats. Two or four flats as required.

Tool Joint Material
All Rods feature hardened European 4140 alloy steel tool joints.

RC Drill Pipe Thread Types
Remet, Metzke, RRE, Drillstar, LW, TS & other threads available.

Robot welding technology
Independently tested & certified to exceed welding standard AS3992

RC Drill Rods Length & Size
Standard lengths from 1 to 6m in 3", 3 ½", 4", 4 ½", 75mm & 78mm diameters.

Reverse Circulation Drill Rods Sealing Options
RC Rods with standard O-ring set up or improved urethane seal options.

Other Rods - Blast Hole
We manufacture RAB, Cubex & API Rods as well as rods to your requirements.

Sizes 3", 3 ½", 4", 4 ½", 75mm and 78mm
Thread Types Remet, Metzke, RRE, Westrod, LW, TS and other threads

REVERSE CIRCULATION DRILL ROD SPECIFICATIONS
Thread Type Remet Remet Remet Metzke Metzke Matrix Matrix
Rod O.D. 3 1/2" 4" 4 1/2" 4" 4 1/2" 4" 4 1/2"
Outer Tube O.D. 88.9mm 101.7mm 114.3mm 101.7mm 114.3mm 101.7mm 114.3mm
Outer Tube I.D. 81.8mm 94.6mm 107.2mm 94.6mm 107.2mm 94.6mm 107.2mm
Outer Tube W.T. 5.3mm 7.1mm 7.1mm 7.1mm 7.1mm 7.1mm 7.1mm
Inner Tube O.D. 38.1mm 50.8mm 63.5mm 50.8mm 63.5mm 50.8mm 63.5mm
Inner Tube I.D. 32.6mm 45.3mm 58mm 45.3mm 58mm 45.3mm 58mm
Inner Tube W.T. 5.5mm 5.5mm 5.5mm 5.5mm 5.5mm 5.5mm 5.5mm
Spanner Flat 90mm 90mm 90mm 90mm 90mm 90mm 90mm
Weight 3.0m 75kg. 75kg. 95kg. 75kg. 95kg. 75kg. 95kg.
Weight 6.0m 120kg. 150kg. 168kg. 150kg. 168kg. 150kg. 168kg.



Pictures

RC Drill Rods RC Drill Pipe 4 1/2 Inch Remet Thread For Atlas Copco Secoroc RC45 RC50 RC Hammer Drilling

RC Drill Rods RC Drill Pipe 4 1/2 Inch Remet Thread For Atlas Copco Secoroc RC45 RC50 RC Hammer Drilling
