UPVC Plastic Screen Casing Pipe Tube For Water Well High Strength For Borewell
UPVC Plastic Screen Casing Pipe Tube For Water Well High Strength For Borewell
UPVC Plastic Screen Casing Pipe Tube For Water Well High Strength For Borewell
UPVC Plastic Screen Casing Pipe Tube For Water Well High Strength For Borewell
UPVC Plastic Screen Casing Pipe Tube For Water Well High Strength For Borewell
UPVC Plastic Screen Casing Pipe Tube For Water Well High Strength For Borewell
UPVC Plastic Screen Casing Pipe Tube For Water Well High Strength For Borewell
UPVC Plastic Screen Casing Pipe Tube For Water Well High Strength For Borewell
Specifications
Brand Name :
ROSCHEN
Model Number :
20 ~ 600mm
Certification :
ISO
Place of Origin :
CHINA
MOQ :
5 PCS
Price :
Negotiate
Supply Ability :
10000000 pcs
Packaging Details :
wooden box
Description

UPVC PVC Plastic Screen Tube for Water Well Casing Pipe and Screen Pipes Tubes for borewell



UPVC PVC Plastic Screen Tube Basic Info.
After-sales Service Good Service
Warranty 50 Years
Material PVC
Kind Thermosetting Plastics Pipe
Water Absorption ＜0.01%
Contraction Percentage 1.5%~5.0%
Tensile Strength High Strength
Trademark ROSCHEN
Transport Package as Per Request
Specification 2 inch 4 inch
HS Code 39172300



Product Description

Socket End and Flush Thread End PVC screen Pipe tube for Water Well drilling, Screen Pipe Casing and Screen Pipe Tube Blue, White Color for Africa, European, America, Latin America Market water well drilling.

Roschen uPVC Well Casing Pipe and Screen Pipes Tube are an ideal prodcut for protection of domestic, irrigation, industrial & mining bore wells, keeping out the gravel pack and foreign particals providing clean and clear water from the bore wells.

Common Size and working pressure as table below:

DN(INCH) OD(MM) Working Pressure Wall Thickness Working Pressure Wall Thickness Working Pressure Wall Thickness
mpa mm mpa mm mpa mm
1/2" 20 2 2
3/4" 25 1.6 2
1" 32 1.25 2 1.6 2.4
1-1/4" 40 1 2 1.25 2.4 1.6 3
1-1/2" 50 1 2.4 1.25 3 1.6 3.7
2" 63 1 3 1.25 3.8 1.6 4.7
3" 90 1 4.3 1.25 5.4 1.6 6.7
4" 110 1 4.2 1.25 5.3 1.6 6.6
4-1/2" 125 1 4.8 1.25 6 1.6 7.4
5" 140 1 5.4 1.25 6.7 1.6 8.3
6" 160 1 6.2 1.25 7.7 1.6 9.5
7" 180 1 6.9 1.25 8.6 1.6 10.7
8" 200 1 7.7 1.25 9.6 1.6 11.9
9" 225 1 8.6 1.25 10.8 1.6 13.4
10" 250 1 9.6 1.25 11.9 1.6 14.8
12" 280 1 10.7 1.25 13.4 1.6 16.6
13" 315 1 12.1 1.25 15 1.6 18.7



Physical and mechanicla properties of pvc pipe for well
Item Indicators Unit
Density 1350~1460 kg/m3
Vicat softening temperature ≥80 ºC
Longitudinal retraction rate ≤5 %
Ring stiffness SN≥12.5 kN/ m2
Tensile yield stress ≥40 Mpa
Drop hammer impact strength ≤5 (0ºC)TIR/%


UPVC Plastic Screen Casing Pipe Tube For Water Well High Strength For Borewell
