Drag Tricone Drill Bit With 3 Wing 4 Wing 5 Wing For Water Well Drilling
Drag Tricone Drill Bit With 3 Wing 4 Wing 5 Wing For Water Well Drilling
Drag Tricone Drill Bit With 3 Wing 4 Wing 5 Wing For Water Well Drilling
Drag Tricone Drill Bit With 3 Wing 4 Wing 5 Wing For Water Well Drilling
Drag Tricone Drill Bit With 3 Wing 4 Wing 5 Wing For Water Well Drilling
Drag Tricone Drill Bit With 3 Wing 4 Wing 5 Wing For Water Well Drilling
Drag Tricone Drill Bit With 3 Wing 4 Wing 5 Wing For Water Well Drilling
Drag Tricone Drill Bit With 3 Wing 4 Wing 5 Wing For Water Well Drilling
Specifications
Brand Name :
ROSCHEN
Model Number :
3 ~ 48"
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
Negotiate
Supply Ability :
100000 pcs
Packaging Details :
Poly wooden box
Description

Drag Bit with 3 Wing 4 Wing 5 Wing for Water Well Drilling

Product Details:
Place of Origin: China
Brand Name: OilMan
Certification: API & ISO
Model Number: PDC Drag bit
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: USD50-600/spc
Packaging Details: Export Wooden Case
Delivery Time: 7-15 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 800 pcs per month

Description of PDC Drag Bits:

PDC Concave Bit is a full-scale drilling bit, mainly be used in construction ,mining, geology, coal, water conservancy and hydropower, highway, high speed railway and bridge etc.


Detail Information
Product Description
Product Name: PDC Drag Bit PDC Drill Bit 3 Wing 4 Wing 5 Wing Drag Bit For Water Well Drilling
Suitable Rock: Mud Stone, Limestone, Shale, Sandstone And Granite Etc.
Drag Bit Size: 2 3/8"~ 26"
Cutting Teeth: Tunsten Carbide Material
High Light: Well Drilling Dth Hammer Drill Bits
Dth Hammer Drill Bits 3 Wing
Keywords: Water Well Drilling Drag Bit
Warranty: One Year
Use: Geological Exploration, Coal Mining, Water Well Drilling, Etc
Wings: 3 Wings, 4 Wings, 5 Wings, 6 Wings Drag Bits



PDC Drag Bits:

Product: PDC drag bits
Size: 60mm - 660mm
Wings: 3 wings, 4 wings, 5 wings, 6 wings
Condition: Brand new PDC cutter drag bit
Drilling formation: Soft to hard rock formation
Application: Water well, oil well, ore well drilling
Connection: API reg pin/ box thread
Gauge protection: with
Color: Blue, Golden, Silvery

Features:

1. Soft to medium-hard formation application
Medium Parabolic crown profile and heavy cutter density provide high ROP in medium to hard formations with medium compressive strength and small abrasive layers.
2. Multi-function hydraulics
The deep blade design can get high ROP in medium to hard formations and can effectively cool the bit in hard and abrasive formations
3. Longer Bit Life
High intensified gauge design provides for long runs on steerable system through hard and abrasive formations as steering application.


PDC Drag Bits Specifications:

Size

(Inch)

Size

(mm)

 Std. API thread

Approximate weight

(kgs)
2-3/8 60 Non-std. 1.3
2-1/2 63.5 Non-std. 1.5
3 76 Non-std. 2
3-1/2 89 Non-std. 3.5
3-7/8 98.4 2-3/8" 5
4 102 2-3/8" 5.5
4-1/4 108 2-3/8" 6.5
4-5/8 117.5 2-7/8" 8
5-1/4 133 2-7/8" 11
5-5/8 142.9 3-1/2" 13
5-7/8 149.2 3-1/2" 14
6 152 3-1/2" 17
6-1/8 155.6 3-1/2" 18
6-1/4 159.3 3-1/2" 20
6-1/2 165 3-1/2" 22
7-1/2 190.5 4-1/2" 31
7-5/8 193.7 4-1/2" 32
7-7/8 200 4-1/2" 35
8-1/2 215.9 4-1/2" 42
8-5/8 219 4-1/2" 44
8-3/4 222.3 4-1/2" 45
9-1/2 241.3 6-5/8" 60
9-5/8 244.5 6-5/8" 65
9-3/4 247.7 6-5/8" 70
9-7/8 250.8 6-5/8" 75
10-5/8 270 6-5/8" 82
11-5/8 295 6-5/8" 90
12-1/4 311.2 6-5/8" 98
13-5/8 346.1 6-5/8" 134
15-1/2 394 6-5/8" 190
16 406.4 6-5/8" 200
17-1/2 444.5 7-5/8" 251
20 508 7-5/8" 300
24 610 7-5/8" 600
26 660.4 7-5/8" 700
