Ex Audible Visual Alarm Explosion Proof Siren 90dB 120dB 180dB DC36V IP66
Ex Audible Visual Alarm Explosion Proof Siren 90dB 120dB 180dB DC36V IP66
Ex Audible Visual Alarm Explosion Proof Siren 90dB 120dB 180dB DC36V IP66
Ex Audible Visual Alarm Explosion Proof Siren 90dB 120dB 180dB DC36V IP66
Specifications
Brand Name :
CrownExtra
Model Number :
GYJ
Certification :
ATEX
Place of Origin :
Jiangsu,China
MOQ :
1PC
Price :
USD26-USD99/pc
Payment Terms :
T/T
Supply Ability :
50000PCS Per Month
Delivery Time :
5 days
Packaging Details :
6PCS/Carton
Model No :
GYJ
DB :
90dB/120dB/180dB
Voltage: :
AC220V/DC24V/ DC36V
Colors :
Red/Yellow/Green/Blue
Protection grade :
IP66
Material :
Aluminum
Mounting Styles :
Wall Bracket; Base
Rate :
Ex d IIC T6 IP66
Description

Ex Audible Visual Alarm Explosion Proof Siren 90dB 120dB 180dB DC36V IP66

Applications
1. Widely used for alarming on various marine platforms, chemical tankers, LNG ships and dangerous cargo wharfs etc.
2.Can be equipped with solar panels powered by solar energy, using more than 15 hours on a single charge
3. Can be used in zone 1, 2 & 21, 22
4. Typical applications include:
Oil and gas industries
Chemical, petrochemical
Pharmaceutical industries
Pulp and Paper
Waste and sewage treatment
Power Generation.
5.Housing is made of die-cast aluminum, with epoxy sprayed.
Features
1. Enclosure is of special aluminum alloy, powder coated surface after special corrosion-proof treatment.
2. Toughened glass transparent cover, stands high energy impact, with high light transmittance.
3. Ultra-bright LED light source, more long life.
4. There are four light colors: red, blue, yellow and green etc...
Standard Materials
Housing: Die-casting aluminum
Exterior: Stainless steel
Globe: Tempered glass
Gasket: Silicon rubber
Ex Marking
Ex d e IIC T6, IP66
Input Voltage
AC220V/DC24V/ DC36V
Power consumption [W]
 5W 5~10W 40W
Sound Intensity
90; 120; 180
Flash Frequency
150 times/Min
Color
Red, Yellow, Blue, Green etc...
Mounting Styles
G 3/4"
Conduit Entries
Wall Bracket; Base
Net Weight
1.8kg; 2.5kg；2.7kg; 3.7kg
Corrosion Resistant
WF1

Dimension & Installation [mm]
Ex Audible Visual Alarm Explosion Proof Siren 90dB 120dB 180dB DC36V IP66

Ex Audible Visual Alarm Explosion Proof Siren 90dB 120dB 180dB DC36V IP66
