Specifications
Brand Name :
Crown Extra
Model Number :
GYD810
Certification :
CE, ROHS, ISO. ATEX,
Place of Origin :
China,Jiangsu
MOQ :
1 piece
Price :
usd38-85 per piece
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
3000 pieces per month
Delivery Time :
7 working days
Packaging Details :
Led Lights will be packed in carton, pallet
Product name :
Explosion Proof High Bay Led Lights
Material :
Die-casting aluminum
Color Temperature(CCT) :
5900K
Lamp Luminous Efficiency :
135 lm/w
CRI (Ra>) :
70
Certificate :
CNEX, ATEX, CE, RoHS
Application Area :
Zone 2,21,22
Driver brand :
MEANWELL XLG
Input voltage :
100-295 v
Wattage :
30w-240w
Description

ATEX Certified Explosion Proof Lamp Led Explosion-Proof Industrial Lights


Features:

1. Zone 2, Zone 21&22
2. Instant on crisp white light output
3. High efficiency drivers and LEDs provide, low cost operation in harsh and heavy industrial
4. Isolated LED compartment reduces temperature within driver housing
5. Environmental-friendly and energy saving, simple shape, easy installation
6. Constant current output, stable performance
7. Low power consumption, high light efficiency, good color rendering property
8. Widely used in factories, warehouses, stadiums and other panoramic lighting


Specification:

ELECTRIC
Operating voltageAC 100-295V (50-60Hz)Power consumption30W/40W/50W/70W/100W
MECHANICAL
Humidity10%~95%RHAnti-corrosionWF2
Operating temperature-30 ̊C ~ +60 ̊CCable entryM25*1.5/NPT 3/4”cable entry, suitable for ø10 ~ ø14mm² cable ≤2.5mm² conductor
Weight7KgIP ClassIP65
InstallationBracket mount, ceiling mount, 30° wall mount, guardrail mount, flange mount
CERTIFICATION LABEL
StandardGB3836.1-2010,GB3836.2-2010, GB12476.1-2000,
IEC60079-0:2011, IEC60079-1:2007,IEC60079-31:2008,
EN60079-0:2009,EN60079-1:2007,EN60079-31:2009



Application:

Oil and Gas industry
1. All petroleum production and refining
2. Petroleum storage and retail
Chemical industry
1. All types of paint facilities
2. Chemical production and storage
Metal treatment
1. Steel and aluminum factories
2. Pumping stations in any environment
3. Metal smelting, foundry and fabrication
Food and alcohol industry
1. Flour and fine particle production and storage
2. Food and distilling production
3. Alcohol industry
Other high humidity, high dust, high temperature, vapor locations



Installation Instructions:
Before installation, check voltage, power and other parameters carefully and
make installation preparations arrordingly to layout circuit.
1. organize firstly supporting spare parts and accessories
2. do shut off power before installation
3. the loading capacity of the ceilingfixed item where the lamp is installed should be the same as the lamp weight
4. do power-on test to make sure the lamp can be lighted
5. make sure the lamp is installed firmly, turn on the light finally

Company information:

Crown Extra Lighting Co., Ltd. is a comprehensive enterprise integrating R&D, production, sales and service.
The company is located in Changzhou, known as the "Dragon City" in the Yangtze River
Delta of China. The company is committed to becoming a provider of green, environmentally friendly,
energy-saving, and leading industrial lighting solutions, providing high-quality lighting products for
petroleum, petrochemical, electric power, metallurgy, railways, aerospace, military, public security,
fire fighting, ships, roads, pharmaceuticals, etc. And professional technical service programs.


FAQ:

Q1. Can I have a sample order for explosion-proof led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2: What kind of payments do you accept?
A:T/T, L/C, Western Union,, MoneyGram, etc..

Q3:What is you main products?
A: Explosion-proof LED light ,explosion-proof box,explosion proof fittings, etc.

Q4: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.

Q5: What's the MOQ?
A:MOQ is 1 set.
