800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light
800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light
800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light
800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light
800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light
800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light
800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light
800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light
800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light
800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light
800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light
800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light
Specifications
Brand Name :
E-lite
Model Number :
EL-NED-800(SP)
Certification :
UL ETL DLC CB CE RoHS SAA
Place of Origin :
China
MOQ :
5
Price :
Please contact us to obtain a quote
Payment Terms :
L/C, D/A, D/P, T/T, PAYPAL
Supply Ability :
100,000PCS PER MONTH
Delivery Time :
2-4 WEEKS
Packaging Details :
CARTON BOX
High Power :
800W
LED Driver :
Sosen/Meanwell
LED Chip :
Lumileds 5050
Efficacy :
160 LPW
Lumens :
128000 lm
Colour Temperature :
4500~5500K (2500~5500K Optional)
Description

800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light

High Power Sports Light:

120W 200W 300W 400W 600W 800W 960W 1200W led flood light airport light led stadium 30m high mast light is Low-profile, lightweight, powerful and reliable. Designed with high protection level up to IP67, High impact resistance.


High lumen efficiency of up to 160LM/W, flicker free, and RA>70, meeting the lighting requirements of HD TV broadcasting for sports events.
The professional and unique pin heat sink design creates superb ventilative efficiency.

Air is freely flowable among the pins in any direction, maximizing heat dissipation and lifespan of the LEDs. Optimized engineered design, slim and light weight, no clunky components, significantly reducing shipping and labor, and safer to use on your existing infrastructure.


Various distribution option for various applications, 30×120°, 40×100°, 60×100°, 60×120°, 70×135°, 75×150°, 80×150° option.


Intelligent Zigbee controller, supports wireless on/off, dimming, color turning, grouping, status monitoring, remote control, all simply and easily via smartphone.

DownLoad

2019 E-Lite NEW EDGE Modular Sports Light(160~165L...

Parameter:

Wattage High Power 800W
Input Voltage AC 100~277 V/ AC 200~480 V
LED Driver Sosen/Meanwell
LED Chip Lumileds
Power Factor ≥0.95
Efficacy 160~165 lm/W
Luminous Flux 128000lm
CRI ≥70
Lumen Maintenance L70>150,000 Hrs
Colour Temperature 4500~5500K (2500~5500K Optional)
Beam Angle 30×120°, 40×100°
60×100°, 60×120°
70×135°, 75×150°
80×150°
IP Rating IP66
Operating Temperature -30 to 60°C (-22 to 140°F)
Dimensions 778x366x165mm
Net Weight 17.5kg

800W Sports Light Advantage:

Housing: Pure Aluminum A6063

Thermal Conductivity: 226W/m.K

PC Lens offer resistance to UV and visible radiations.

PC lens can be used to outdoor directly to sunshine and will not turn yellow even after 5 years.

800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light

800W LED Sports Lighting / 6000K Asymmetric Sport Light 160LPW LED Stadium Light

High thermal conductivity:

We use A6063 pure Aluminum, with 223 w/m.k thermal conductivity (VS. Typical ADC12 Aluminum with only 98 w/m.k)


Slim and Lightweight:

Optimized engineered design, slim and lightweight, no clunky components, significantly reducing shipping and labor, and safer to use on your existing infrastructure.

Extraordinary Thermal Management:

The professional and unique pin heat sink design creates superb ventilative efficiency. Air is freely flowable among the pins in any direction, maximizing heat dissipation and lifespan of the LEDs.

Intelligent controller:

Intelligent Zigbee controller, Photocell, Microwave, IOT System. Supports wireless on/off, dimming, color turning, grouping, status monitoring, remote control, all simply and easily via smartphone.
