1200W LED High Mast Light Powerful / 19,2000 lm LED Flood Light for Soccer Field
1200W LED High Mast Light Powerful / 19,2000 lm LED Flood Light for Soccer Field
1200W LED High Mast Light Powerful / 19,2000 lm LED Flood Light for Soccer Field
1200W LED High Mast Light Powerful / 19,2000 lm LED Flood Light for Soccer Field
1200W LED High Mast Light Powerful / 19,2000 lm LED Flood Light for Soccer Field
1200W LED High Mast Light Powerful / 19,2000 lm LED Flood Light for Soccer Field
1200W LED High Mast Light Powerful / 19,2000 lm LED Flood Light for Soccer Field
1200W LED High Mast Light Powerful / 19,2000 lm LED Flood Light for Soccer Field
Specifications
Brand Name :
E-lite
Model Number :
New Edge Series Modular High Mast Light
Certification :
UL ETL DLC CB CE RoHS SAA
Place of Origin :
China
MOQ :
5
Price :
Please contact us to obtain a quote
Payment Terms :
Please contact us to obtain a quote
Supply Ability :
100,000PCS PER MONTH
Delivery Time :
2-4 WEEKS
Packaging Details :
CARTON BOX
High Power :
1200W
High Lumen :
19,2000 lm
Efficacy :
165 lm/W
Colour Temperature :
4500~5500K (2500~5500K Optional)
Beam Angle :
30×120°,40×100° 60×100°,60×120° 90°,110° ,150° 70×135° ,75×150° 80×150°
Operating Temperature :
-30 to 60°C (-22 to 140°F)
Description

1200W LED High Mast Light Powerful / 19,2000 lm LED Flood Light for Soccer Field

■ Features
· System Light Efficacy 165 LPW
· Ultra Bright, Up to 192,000Lm
· Flexible, Modular Design
· Multiple Choice of Optical Lenses
· Easy Installation & Maintenance
· Five Years Warranty
· IP66

Wattage 300W 400W 600W 800W 960W 1200W
Modular Quantity 3 4 5 7 8 10
Input Voltage AC 100~277 V/ AC 200~480 V
LED Driver Sosen
LED Chip Lumileds
Power Factor ≥0.95
Efficacy 160-165lm/W
Luminous Flux 49,500lm 66,000 lm 96,000 lm 128,000lm 153,600lm 192,000lm
CRI ≥70
Lumen Maintenance L70>150,000 Hrs ( Tm-21 Calculation )
Colour Temperature 4500~5500K (2500~5500K Optional)
Beam Angle 30x120° 40x100° 60x100° 60x120° 70x135° 75x150° 80x150°
IP Rating IP66
Operating Temperature -30 to 60°C (-22 to 140°F)
Dimensions 402x366x145mm 496x366x145mm 590x366x145mm 778x366x165mm 872x366x165mm 1060x366x165mm
Net Weight 7.5 kg 7.9 kg 12.5 kg 17.5 kg 20.3 kg 25.7 kg
Certification ETL DLC CB GS TUV CE ROHS SAA
Warranty 5 years
Material Aluminum Alloy

Product Advantage:

1. Customized high power Lumileds LED chips, luminous efficiency is up to 165Lm/W.


2. Super high luminous efficiency to meet the customers' requirements of high luminous flux and less weight with low power.


3. Modular pluggable technology, easy tool onsite maintenance;


4. Honeycomb and whole structure cooling technology, high efficient heat dissipation;


5. Non-wire eutectic soldering;


6. Double-coupling IP66 protection, highest waterproof level;


7. Single unit's damage won't affect others' normal work;


8. Intelligent constant current driving technoligy, long life span;


9. Ergonomic light distribution to achieve uniform illuminating effect;


10. Free modular serialization and full power range solutions;


11. Colors: Silve, Grey, Black.


12. Installation ways: hanging, flood light bracket-mounted.

1200W LED High Mast Light Powerful / 19,2000 lm LED Flood Light for Soccer Field

1200W LED High Mast Light Powerful / 19,2000 lm LED Flood Light for Soccer Field

New Edge Series Modular High Mast Light.pdf
