165 LPW High Bay Workshop Lights / 400W luminaire fixture for workshop lighting
165 LPW High Bay Workshop Lights / 400W luminaire fixture for workshop lighting
165 LPW High Bay Workshop Lights / 400W luminaire fixture for workshop lighting
165 LPW High Bay Workshop Lights / 400W luminaire fixture for workshop lighting
165 LPW High Bay Workshop Lights / 400W luminaire fixture for workshop lighting
165 LPW High Bay Workshop Lights / 400W luminaire fixture for workshop lighting
Specifications
Brand Name :
E-lite
Model Number :
New Edge Modular High Bay
Certification :
UL ETL DLC CB CE RoHS SAA
Place of Origin :
China
MOQ :
5
Price :
Please contact us to obtain a quote
Payment Terms :
D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100,000PCS PER MONTH
Delivery Time :
2-4 WEEKS
Packaging Details :
CARTON BOX
Watt :
400W
Lumens :
66,000lm
Efficacy :
165 lm/W
Lumen Maintenance :
L70>150,000 Hrs
Beam Angle :
40×1100° 60×100° 90° 110° 150°
Operating Temperature :
-30 to 60°C (-22 to 140°F)
Description

165 LPW High Bay Workshop Lights / 400W luminaire fixture for workshop lighting

FEATURE:

·System Light Efficacy 160~165 LPW
·Ultra Bright, Up to 96,000Lm
·Flexible, Modular Design
·Multiple Choice of Optical Lenses
·Easy Installation & Maintenance
·Five Years Warranty
·IP66

Wattage 120W 200W 300W 400W 600W
Input Voltage AC 100~277 V/ AC 200~480 V
LED Driver Sosen
LED Chip Lumileds
Power Factor ≥0.95
Efficacy 160-165lm/W
Luminous Flux 19,200 l m 33,000 lm 49,500 lm 66,000 lm 96,000 lm
CRI ≥70
Lumen Maintenance L70>150,000 Hrs ( Tm-21 Calculation )
Colour Temperature 4500~5500K (2500~5500K Optional)
Beam Angle 40×1100° 60×100° 90° 110° 150°
IP Rating IP66
Operating Temperature -30 to 60°C (-22 to 140°F)
Dimensions 221x366x145mm 308x366x145mm 402x366x145mm 496x366x145mm 590x366x145mm
Net Weight 5.4 kg 6.5 kg 7.5 kg 7.9 kg 12.5 kg
Certification ETL DLC CB GS TUV CE ROHS SAA
Warranty 5 years
Material Aluminum Alloy

Advantage:

Die-Casting Alumium

Excellent heat dissipation for long lifespan, Top quality with 5 years warranty.

Electrical Advantage:

LM80 LEDs up to 165lm/W. Frosted Optional for Anti-Glare. Multiple choice of optical lens.

High Quality Meanwell Driver:

Meanwell driver with top brand

100-277V & 347-480V available for all items, 0-10V available.

165 LPW High Bay Workshop Lights / 400W luminaire fixture for workshop lighting
