Modular LED Flood Lights IP66 Outdoor Football Tunnel Stadium Lights
Modular LED Flood Lights IP66 Outdoor Football Tunnel Stadium Lights
Modular LED Flood Lights IP66 Outdoor Football Tunnel Stadium Lights
Modular LED Flood Lights IP66 Outdoor Football Tunnel Stadium Lights
Modular LED Flood Lights IP66 Outdoor Football Tunnel Stadium Lights
Modular LED Flood Lights IP66 Outdoor Football Tunnel Stadium Lights
Specifications
Brand Name :
E-lite
Model Number :
EL-NED-120(SP)
Certification :
UL ETL DLC CB CE RoHS SAA
Place of Origin :
China
MOQ :
5
Price :
Please contact us to obtain a quote
Payment Terms :
L/C, D/A, D/P, T/T, PAYPAL
Supply Ability :
100,000PCS PER MONTH
Delivery Time :
2-4 WEEKS
Packaging Details :
CARTON BOX
Efficacy :
160-165LPW
Kevin :
5000K
Beam Angle :
30×120°,40×100° 60×100°,60×120° 70×135° ,75×150° 80×150°
IP Rating :
IP66
Temperature :
-30 to 60°C (-22 to 140°F)
Wattage :
120W
Description

Modular LED Flood Lights IP66 Outdoor Football Tunnel Stadium Lights

Super Bright & Energy Saving

With Lumileds 5050 LED chips provide up to 160lm/w by lab test, 120w can bring 19200lm brightness. It means that you just need to pay for the 120W led flood light equivalent to other high power and wattage lights, plus 5 FT electric cord with US plug (UL approved). Saving money on purchase and electricity bill.

Wide Angle Lighting Area

Update version illumination range can be improved up to 360°. Totally flexible solution to light up a large and dark areas .E-LITE LED Flood Light bring you more than 1614 sq.ft lighting coverage if mounted on the wall 20ft.With 6.5 ft wall plug cord, this led floodlights can be installed in any area where lighting is needed.

Warranty Policy

11 years manufacturing experiences in Outdoor LED Flood Lights industry ,we are confident to our product , provide 5-years product quality promise, Lifetime Free After-service and Technical Support.

DownLoad

2019 E-Lite NEW EDGE Modular Sports Light(160~165L...

Wattage

120W

Input Voltage

AC 100~277 V/ AC 200~480 V

LED Driver

Sosen

LED Chip

Lumileds

Power Factor

≥0.95

Efficacy

160 lm/W

Luminous Flux

19200 lm

CRI

≥70

Lumen Maintenance

L70>150,000 Hrs

Colour Temperature

4500~5500K (2500~5500K Optional)

Beam Angle

30×120°, 40×100°
60×100°, 60×120°
70×135°, 75×150°
80×150°

IP Rating

IP66

Operating Temperature

-30 to 60°C (-22 to 140°F)

Dimensions

221x366x145mm

Net Weight

5.4 kg

360° Rotatable

  • Adopt safe and high light transmittance PC diffuser.

  • With THREE adjustable heads that pivot 0~360° side to side adjustment and 180° flexible adjustment U bracket . Three timeslighting coverage than other one head flood light fixture.

Excellent Heat Dissipation

  • Exclusive patented cooling technology

  • Four-side air circulation convection

  • Durable die-casting aluminum heat dissipation material.

  • Protect led chips and luminous efficiency, promise long lifespan.

Harsh Weather Resistance

  • IP66 Waterproof, anti-surge,dustproof and oil proof, the protection level reaches IP6K9K.

  • Prevent condensation and fogging, and improve the durability of the product.

  • Heat dissipation and pressure balance , extend the life of outdoor lighting.

  • Chemical resistance, high temperature resistance, anti-aging, etc., improve the reliability of the product in harsh environments.

Typical Applications

·Outdoor Sports Arena and Stadium
·General Flood Lighting


Modular LED Flood Lights IP66 Outdoor Football Tunnel Stadium Lights
Modular LED Flood Lights IP66 Outdoor Football Tunnel Stadium Lights
