Outdoor Stadium Square Park Area Garden Yard Building Billboard Lighting
Outdoor Stadium Square Park Area Garden Yard Building Billboard Lighting
Outdoor Stadium Square Park Area Garden Yard Building Billboard Lighting
Outdoor Stadium Square Park Area Garden Yard Building Billboard Lighting
Outdoor Stadium Square Park Area Garden Yard Building Billboard Lighting
Outdoor Stadium Square Park Area Garden Yard Building Billboard Lighting
Outdoor Stadium Square Park Area Garden Yard Building Billboard Lighting
Outdoor Stadium Square Park Area Garden Yard Building Billboard Lighting
Specifications
Brand Name :
E-lite
Model Number :
Modular Area Lighting
Certification :
UL ETL DLC CB CE RoHS SAA
Place of Origin :
China
MOQ :
5
Price :
Please contact us to obtain a quote
Payment Terms :
L/C, D/A, D/P, T/T, PAYPAL
Supply Ability :
100,000PCS PER MONTH
Delivery Time :
2-4 WEEKS
Packaging Details :
CARTON BOX
Housing Material :
6063 Aluminum
Certificate :
ETL DLC CB CE ROHS
Working Life-span: :
50000hrs
Efficacy :
180 lm/W
Beam Angle :
Asymmetric distribution
Operating Temperature :
-30 to 60°C (-22 to 140°F)
Description

Outdoor Stadium Square Park Area Garden Yard Building Billboard Lighting

Installation Caution :

1. Please turn off the power before installation and ensure that the installation site can support the weight of the fixture.
2. In order to prevent the lamp off, make sure the installation is correct.
3. Do not use in a corrosive gas.
4. Do not cover any material in the body.
5. For safety, please tangible take a good ground.
6. Decomposition of the product, modification, or improper construction .

Product Description:

1.Beam Angle Adjustable. Wide radiation angle, huge lighting area;

2. End caps: Using die-Casting aluminum, good looking, and excellent loading-bearing structure;

3. Heat sink: Using stretching aluminum material, high purity; Back part: Using stainless steel material, no need worry that it will get rusty;

4. High quality lens, impurity-free,effective lighting and low power consumption ;

5. Having ventilate holes at the place of driver box, it won't pond water, so it is no need to worry that driver will be wetted.

6. The spray-Finishing skill works well, and paint will not be peeled off.

7. No UV & IR, No Blinking and No Mercury & Lead free;

8. Meet different customers' requirements, it is easy to install and maintain;

Product specification:

Wattage 100W 150W 200W 300W
Input Voltage AC 100~277 V/ AC 200~480 V
LED Driver Sosen
LED Chip Lumileds
Power Factor ≥0.95
Efficacy 180lm/W
Luminous Flux 18,000 lm 27,000 lm 36,000 lm 54,000 lm
CRI ≥70
Lumen Maintenance L70>150,000 Hrs ( Tm-21 Calculation )
Colour Temperature 4500~5500K (2500~5500K Optional)
Beam Angle 30×120° 40×100° 60×100° 60×120°
90° 110° 150°
70×135° 75×150° 80×150°
IP Rating IP66
Operating Temperature -30 to 60°C (-22 to 140°F)
Dimensions 597x358x82mm 711x362x85mm 805x362x85mm 966x365x224mm
Net Weight 6.5 kg 7.5 kg 8.6 kg 14.8 kg
Certification ETL DLC CB GS TUV CE ROHS SAA
Warranty 5 years
Material Aluminum Alloy

FAQ:

Q1. Can I have a sample order for led light?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than

Q3. Do you have any MOQ limit for led light order?

A: Low MOQ, 2 pcs for sample checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. Is it OK to print my logo on led light product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q6: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.

Outdoor Stadium Square Park Area Garden Yard Building Billboard Lighting

Outdoor Stadium Square Park Area Garden Yard Building Billboard Lighting

2019 E-Lite Modular LED Area Lighting Catalog..pdf...
