Specifications
Brand Name :
E-lite
Model Number :
Grapheneism™ 140LPM High Bay
Certification :
UL ETL DLC CB CE RoHS SAA
Place of Origin :
China
MOQ :
5
Price :
Please contact us to obtain a quote
Payment Terms :
L/C, D/A, D/P, T/T, PAYPAL
Supply Ability :
100,000PCS PER MONTH
Delivery Time :
2-4 WEEKS
Packaging Details :
CARTON BOX
Mount :
NPT Metal
Reflector :
PC
Input Wattage :
277V
Delivered Lumens :
33600lm
Lumens Output :
140LPW
Wattage :
240W MAX
Description

UFO LED High Bay Lighting | Save on High Efficiency Lights‎ LM80 TM-21 CB Listed

We built this light to enable you to build a bright constellation of your own. DLC Premium Rated, Separate Driver and a 3.3Ft power cord!

  • BETTER DESIGN - 240 Watt is powered by CREE 2835 LED modules producing 140 Lumens per watt - Save even more by using a lower watt unit. Premium grade components make this an industrial grade LED High Bay or Warehouse Light.

  • LONG CORD - 3.3 foot whip or power cord included

  • DIMMABLE: Series has a 1-10 volt dimmable driver. Compatible with 0-10v, PMW resistance compatible devices and switches.

  • SMALLER SIZE - New 'UFO style' is the latest in LED technology. Smaller, longer lasting and more efficient. Only 11 inches (290mm) in diameter, the new design is more compact without sacrificing performance. Stop replacing old Metal Halide, HID or CFL bulbs. Use the Corvus UFO High Bay LED light.

  • EASY INSTALLATION - 3.3ft Whip (power cord) ! included cord is 3.3ft long for easier install. Preinstalled Hook makes installation easy. Simple replacement for existing lights or for new installation. M10 threads for alternate install. Product Weight only 10.52LB for easy handling.

  • BRIGHT, DIRECT and BUILT TO LAST - 5000K color ensures a clear bright light. 110 Degree angle of light creates a wide even light. 100,000 LED saves having to replace bulbs- Aluminum Housing with high tech Heat Sink protects the LED Driver. Better Heat dissipation ensures longer LED life and safety. Glass lens. IP65 Waterproof for all conditions. All backed by a 5 year warranty.

  • UL AND DLC Premium 4.4 Rated - UL listed for safety and DLC Premium 4.4 for energy rebates. DLC stands for Design Lighting Consortium and verifies actual light performance. This 240 watt unit is verified at over 136 Lumens to watt! Use PL7PAENFQYWN to find.

Specification:

  • Input Wattage: 240 Watt
  • Replacement Wattage 750 Watt Metal Halide
  • Input Voltage Range 100-277V (multivolt Driver)
  • Delivered Lumens 33,600 Lumen
  • Efficiency: 145 Lumen to watt, certified at 136.21LM/Watt (DLC Premium level testing)
  • Dimmable: 0-10v compatible
  • Color Rendering Index (CRI) 84+
  • 5000K Bright White Color
  • Beam Angle 110°
  • Power Factor 0.98
  • Frequency 50/60Hz MAX THD (%) 14
  • Min. Ambient Temp -40.0°F / 40°C - Max Ambient Temp 122°F / 50°c
  • IP Rating IP65
  • Product Weight 100-150 Watt is 8.2LB / 3.7KG, 200-240 is 10.2lb
  • Product Height (with Hook) 100-150 watt; 7.5inches/ 193mm, 200 and 240 watt; 8.5" /215mm
  • Product Diameter 100 to 150 Watt: 11.7" / 298mm, 200-240 watt: 14" / 360mm
  • Glass Lens
  • Materials Die Cast Aluminum
  • Finish Black
  • LM90 - 36000 hours
  • Life Time 100,000 Hours
  • UL Listed: E489165
  • DLC Listed: Premium + 4.4
  • Warranty 5 Years Rock Solid

Download
2019 E-Lite Grapheneism UFO High Bay (140LPW, 100W...

Wattage

 100W 150W

200W

 240W

Input Voltage

AC 100~277 V/ AC 200~480 V

LED Driver

E-Lite / Sosen

LED Chip

Lumileds / CREE

Power Factor

≥0.95

Efficacy

140 lm/W

Luminous Flux

 14,000lm 21000lm

28,000 lm

 33,600lm

CRI

≥70

Lumen Maintenance

L70>120,000 Hrs

Colour Temperature

4500~5500K (2500~5500K Optional)

Beam Angle

90° Ribbed Lens
120° Ribbed Lens
120° Clear Flat Lens
120° Diffused Dome Lens
120° Clear Dome Lens
90° Reflector
100° Reflector

IP Rating

IP65 & IP69K

Operating Temperature

-30 to 45°C (-22 to 113°F)

Dimensions

325x325x183mm Max

Net Weight

 2.9kg 3,3kg

5.3 kg

 5.6kg

Certification

ETL DLC CB GS TUV CE ROHS SAA

Warranty

5 years

Material

Graphene Composite Hear Sink

Easy Installation with US Hook:

When the customer installs the light, the luminaire is usually hung on the round hook. If the hook on the luminaire is also round, then the customer must purchase the joint to complete the installation; but if you choose High Bay Lights, then you don't have to be so troublesome at all. High bay lights are specially customised with US hooks for easy installation. You only need to rotate the hook to the lamp, then connect the hook to the hanger and tighten the screw. There is no need to purchase additional accessories to easily complete the installation of the fixture.


UFO LED High Bay Lighting Save on High Efficiency Lights‎ LM80 TM-21 CB Listed


Product Overview:

UFO style LED high bay performance lighting. That's 5 Years and over 25,000 UFOs sold. As one of the original suppliers to switch to UFOs, we know how to make a better high bay light. This 2020 series takes everything we know about great high bay lighting and bring the price even lower. CREE 2835 LEDs bring the high CRI, while an aluminum body and separated driver keep away the heat. A classic design and 3.3ft cord make this the first choice in high bay lights.

UFO Style' these lights are the latest in LED technology. Smaller size and more efficient than the traditional High Bay Lights, these look better, last longer and are easier to install.

Replace your old high bay lights, warehouse lights or retail lights with a high efficiency LED area light. Save money and replace bulbs less often with a 100,000 hour rated LED. Fixture is also ideal for new installations. Save money and improve lighting
