Specifications
Brand Name :
E-lite
Model Number :
Edge™ 60°C High Bay
Certification :
UL ETL DLC CB CE RoHS SAA
Place of Origin :
China
MOQ :
5
Price :
Please contact us to obtain a quote
Payment Terms :
L/C, D/A, D/P, T/T, PAYPAL
Supply Ability :
100,000PCS PER MONTH
Delivery Time :
2-4 WEEKS
Packaging Details :
CARTON BOX
Wattage :
300W
Lumens :
36000lm
LED Chips :
Osram / Lumileds
LED Driver :
Sosen / Inventronics
Lumen Maintenance :
L70>100,000 hours TM-21 Calculated
Operating Temperature :
-30 to 60°C (-22 to 140°F)
Description

200W High Temperature LED Lights / Special High Bay for hazardous and industrial

Offering the widest range of hazardous certifications in the industry, Elite High Bay robustly with stands the harshest conditions and virtually eliminates lighting maintenance to improve site efficiency and safety. Designed for use in oil and gas (including offshore), chemical, mining, pulp & paper and other volatile environments. The EDGE High Bay is rated for over 150,000 hours and most models are covered by Elite 5-10 year warranty.

Product Spec:

Part Number

EO-ED-150

Watts

150

Lumens

19,500lm

Replaces

400W Metal Halide/HPS

Lumens Per Watt

130lm/w

Voltage

100-277V / 347-480V

Frequency

50/60 hz

Power Factor

> .95

THD

< 15%

Life Hours

100,000 hours

Color Temp

4000K | 5000K | 6000K

CRI

70+

Beam Angle

13 types of Beam Angle

Operating Temp

-30 to 60°C (-22 to 140°F)

IP Rating

IP66

Dimmable

Option

Dimensions

402x366x245mm

Weight

19 lbs

Warranty

5 years

Related Wattage:

Input Power Equivalent Lumen Output(IES) Input Voltage LED Chip Color Temp CRI Operating Temp Light Efficacy
100W 250W HID 13000lm 100-277 VAC
200/480 VAC
Lumileds

4000K

5000K

6000K

7000K

>70 -30 to 60°C
(-22 to 140°F)
130 LPW
150W 400W HID 19500lm
200W 750W HID 26000lm
300W 1000W HID 39000lm
450W 1500W HID 58500lm
650W 2000W HID 78000lm
750W 2500W HID 90000lm

Applications

  • Oil & Gas

  • Mining

  • Food processing

  • Foundries

  • Power Generation

  • Paper and Pulp Mills

  • Grain Mills

  • Desalination Plants

  • Chemical Plants

  • Water & Sewage

150W High Temperature LED Lights / Special High Bay For Hazardous And Industrial

Product Features:

• Perfect Light Distribution Solution: Adoption of integrated shell optic lens, enhance the brightness and illumination uniformity.

• There are 13-types of degree beam angle options for the Lens.

• Scientifically-designed heat dissipater with much better cooling effect.

• High luminous efficiency, Whole lamp output light effiency >130LM/W.

• For the traditional light source such as the High Pressure Sodium, if the voltage fluctuation ±7%, the brightness and lifetime will be reduced very fast, but for BBE LED, even the voltage fluctuation is ±20%, the brightness and lifetime will not be influenced at all;Over Current, Over Voltage, Over Heat, Thunder Protection.

• Impact Resistance, Shock-proof, Without Ultraviolet (UV) and Infrared (IR) Radiation: No filament and glass frames, avoid break of the traditional lamp,without harm to the human body.

• The CCT of Warm white,Neutral white,Pure white to meet the needs of different occasions, eliminated the low color temperature of the sodium lamp which cause the depressed mood, observers will feel more comfortable.
