PP PE PVC 80% CaCO3 Granulating Plastic Filler Masterbatch Extruder Twin Screw
PP PE PVC 80% CaCO3 Granulating Plastic Filler Masterbatch Extruder Twin Screw
PP PE PVC 80% CaCO3 Granulating Plastic Filler Masterbatch Extruder Twin Screw
PP PE PVC 80% CaCO3 Granulating Plastic Filler Masterbatch Extruder Twin Screw
PP PE PVC 80% CaCO3 Granulating Plastic Filler Masterbatch Extruder Twin Screw
PP PE PVC 80% CaCO3 Granulating Plastic Filler Masterbatch Extruder Twin Screw
Specifications
Brand Name :
HLD
Model Number :
H-TSE35B/H-TSE50B/H-TSE65B/H-TSE75B/H-TSE95B
Certification :
SGS/ISO9001/CE
Place of Origin :
Nanjing China
MOQ :
1/set
Price :
face to face /set
Payment Terms :
T/T,
Supply Ability :
200~500 set/year
Delivery Time :
35~45 Days
Packaging Details :
Bubble wrap/ Wrap film/ Wooden box
Name :
CaCO3 Granulating Plastic Filler Masterbatch Extruder
Type :
Compounding and Pelletizing Extruder
Screw Design :
Twin Screw
Screw Elements Material :
W6mo5cr4V2
Electrical brand :
Siemens/ABB/Schneider/Delta/Omron/Other
Screw Rpm :
60-600
Heater :
Copper or aluminum heater/Heating rods
OEM :
Support
Video outgoing-inspection :
Provided
output :
60kg/h~custom
Raw Material :
PP PE PVC Fill 80% CaCO3
Pelletizing System :
Strand Pelletizing/Die Face Pelletizing/Underwater
Description

High Performance Cost Effective PP PE PVC Fill 80% CaCO3 Granulating Plastic Filler Masterbatch Extruder

High Performance Cost Effective PP, PE, PVC Filled with 80% CaCO3 Pellets Plastic Filler Masterbatch Extruder is designed for the production of highly filled plastic masterbatch. It is capable of efficiently extruding plastic pellets containing 80% calcium carbonate (CaCO3) filler for processing plastic substrates such as polypropylene (PP), polyethylene (PE) and polyvinyl chloride (PVC). Its excellent performance and economical cost make it ideal for improving the price/performance ratio of plastic products and reducing production costs.

Model L/D

Output
H-20B 28~60 :1 5~20kg/h
H-36B/40B 28~60 :1 60~150kg/h
H-50B/52B 28~60 :1 150~250kg/h
H-65B 28~60 :1 300~500kg/h
H-75B 28~60 :1 500~750kg/h
H-95B 28~60 :1 800~1500kg/h

Applications

Filling modification PE, PP, EVA, ABS, PC, PS, etc+calcium carbonate, talc, glass beads,
SiO2, aluminum hydroxide. Magnesium hydroxide, brocade oxide, sulfuric acid
PP, PA, ABS, etc. + iron powder, magnetic powder, aluminum powder, stainless steel wire, ceramic powder
Blending modification(rubber and plastic compounding, plastic alloy PE, PP, PS+SBS, PP, PA+EPDM, POE, PP+NBR, EVA + silicone rubber, etc.
PA, PC+ABS: ABS+TPU: PBT+PET: PP+PE, etc.
Masterbatch PE, PP, ABS, EVA, PS, PBT, PET, etc. + pigments and other additives
Biodegradable masterbatch: PE, PS, PP + starch, etc.
Flame retardant masterbatch: PE, PP, PA, ABS, PBT, etc. + flame retardants and other additives
Functional masterbatch Polyethylene master batch,anti-fog and anti-aging, high thermal insulation masterbatch, cooling masterbatch, rheology modified masterbatch
anti-rust masterbatch, stiffening masterbatch, antistatic masterbatch, antibacterial masterbatch
Carbon black masterbatch: PE, EVA, ABS, PET, etc. + carbon black
Glass fibre (Carbon fibre)Reinforcement (MD model short fibre) PP, PBT, ABS, AS, PA, PC, POM, PET, PEEK, PPO, PES, etc. + long glass fiber or short glass fiber
PP, PBT, ABS, AS, PA6, PA66, PC, POM, PET, etc. + long carbon fiber or short carbon fiber
Thermoplastic elastomer TPR, TPU, TPV, SBS, SEBS, SIS, etc
EVA, PU hot melt adhesive, silicone adhesive, UHMWPE spinning
Fluororubber, fluoroplastics, LCP, PEEK, PES, PL, PSU, etc.
Special material Optical cable covering material, acetate fiber, PP cigarette filter material, conductive plastic
TPR, PU, EVA foam sole material
Luminous plastics, antibacterial plastics, anti-UV plastics, PE cross-linkable pipe materials food, pet feed
HDPE, LDPE, LLDPE, MDPE, PP, EVA Insulation material, sheath material, PF Radiation cross-linked cable material, PE Silane cross-linked cable material
Various cable materials Flame retardant polyolefin cable materials, low smoke halogen-free flame retardant cable materials
Low smoke and low halogen flame retardant PVC cable material
Reactive extrusion Polyamide polycondensation reaction, polyester melt polymerization reaction, polyurethane polycondensation reaction, polycarbonate polycondensation reaction, polyoxymethylene bulk continuous polymerization reaction, PMMA polymerization
Devolatilization Chlorinated polypropylene, chlorosulfonated polyethylene, fluorine rubber, butadiene rubber, SBS, EPDM, SEBS, SIS, etc.
Powder coating
Polyester type, epoxy type, acrylic vinegar type, polyurethane type, acrylic vinegar, phenol resin, etc.


PP PE PVC 80% CaCO3 Granulating Plastic Filler Masterbatch Extruder Twin Screw

FAQ
1:How many years of experience do you have?
Over 15 years experience in extruder industry.

2:Are you traders or manufacturers?What is the area of the factory?
We are manufacturer,The factory is over 5000 square meters.
3:Screw and barrel accessories, who is produced?
Our factory manufactures it ourselves
4:Can I have a sample order for extruder?
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
5:How to proceed an order for ?
Firstly ,let us know your requirements or application.
Secondly ,We quote according to your requirements or our suggestions.
Thirdly ,customer confirms the samples and places deposit for formal order.
Fourthly, We arrange the production.
Finally, arrange delivery
6: Provide technology and formula?
For orders over a certain amount, we will provide the technology and formula to help you complete the project.
7: Have a catalogue​?
HLD Album.pdf
