16-32mm PE Pipe Coiler Machine Auto Pipe Winding Machine
16-32mm PE Pipe Coiler Machine Auto Pipe Winding Machine
16-32mm PE Pipe Coiler Machine Auto Pipe Winding Machine
16-32mm PE Pipe Coiler Machine Auto Pipe Winding Machine
Specifications
Brand Name :
KAIDEMAC
Product Name :
Pipe Coiler
Pipe size :
16-32mm
Traver unit :
sermo motor driven type with PLC control
Coiling speed :
up to 60m/min
Description

Plastic Pipe Winding Machine

Pipe Winder 16-32mm diameter range

Below winding machine is special designed as per customer requirement, to wind LDPE pipes 16-32mm. Two working position positions are designded at two sides.

16-32mm PE Pipe Coiler Machine Auto Pipe Winding Machine

Main Technical Parameters:

Model SGJ-32
Working postion Double working position
Winding pipe diameter 16-32mm PE pipe
Traverser unit Servo motor driven type with PLC parameter setting
Coil ID 500-950mm
Coil Width 160-300mm
Coil Height 300mm
Coiling Speed 30m/min

If you have special requirement on coil size, pls contact us freely, we can design the winding machine as per your basic inforamtion.

Technical advantages of KAIDE pipe coiling machine.

  • Servo motor driven pipe traverser unit, with servo motor; To ensure to winding pipe coil with well arrangement, and ensuring high speed coiling.

  • Auto tenstion control, to automatically adjust winding speed.

  • No need operator to help pipe coiling while working; lot of labor cost can be saved.

  • PLC control system with parameter setting; much intelligent and convenient to operate.

  • Coil width and inner diameter size inforamtion are laser printed on the machine, convenient to adjusting

  • Coil length metering, with alarm function, to remind the operater to cut the pipe while reaching setting length

  • Auto stop winding function while detecting cut pipe end; to clamp automatically to prevent coil loosen.

16-32mm PE Pipe Coiler Machine Auto Pipe Winding Machine

16-32mm PE Pipe Coiler Machine Auto Pipe Winding Machine

CONTACT US RIGHT NOW TO GET WINDING MACHIEN WORKING VIDEOS!
