16mm×2.0mm PERT Pipe Extruder Machine Speed 50m/min For PERT Pipe Making
16mm×2.0mm PERT Pipe Extruder Machine Speed 50m/min For PERT Pipe Making
Specifications
Brand Name :
KAIDE
Model Number :
KDSG-60; KDSS-60; KDSS-75
Certification :
CE; ISO
Place of Origin :
Weifang, China
MOQ :
1set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200sets per year
Delivery Time :
60 days
Packaging Details :
Soft film with protection sponge
Product Name :
PERT Pipe Making Machine
Pipe size :
16-32mm
Production Speed :
15m/min; 35m/min and 60m/min
Control system :
SIEMENS PLC control
Pipe Winder :
Semi-Auto; or Fully auto reel change and cutting with packing device
Description

PERT Heating Pipe Extrusion Line / PERT Pipe Extruder Machine

There are mainly three different speed models for PERT pipe extrusion lines, 15m/min speed model, 35m/min speed model and highest speed 60m/min model with fully auto winding machine and package device.

Beow are introduce of 60m/min speed model.

16mm×2.0mm PERT Pipe Extruder Machine Speed 50m/min For PERT Pipe Making

Technical Data of Pipe Production Line

Line Model Screw Diameter L/D Production Scope Production Speed Nominal Power L×W×H

KDRT-75

 ф75mm 36:1 ф16-32mm 60m/min 163KW 58m×2.5m×3m

16mm×2.0mm PERT Pipe Extruder Machine Speed 50m/min For PERT Pipe Making

16mm×2.0mm PERT Pipe Extruder Machine Speed 50m/min For PERT Pipe Making 16mm×2.0mm PERT Pipe Extruder Machine Speed 50m/min For PERT Pipe Making

16mm×2.0mm PERT Pipe Extruder Machine Speed 50m/min For PERT Pipe Making

Extruder

  • High efficient five section type screw and barrel, to ensure fast plasticizing & dispersion effcct.
  • ABB inverter; Schneider electric elements; SIEMENS PLC with remote control
  • Grvametirc material dosing sytem is applied to increase produced pipe quality, and also have benenifs of shorten start-up time, and save raw material.
 16mm×2.0mm PERT Pipe Extruder Machine Speed 50m/min For PERT Pipe Making

Die Head

  • Spiral Pressure storage die head effectively overcomes the instantaneous fluctuation of extrusion pressure, realizing high speed pipe extrusion with stable pressure.
  • High quality mould steel 40Cr; processed by CNC machine with higher precision.
 16mm×2.0mm PERT Pipe Extruder Machine Speed 50m/min For PERT Pipe Making

Vaccum Tank & Cooling Tank

  • vacuum and calibrating system is futher optimized based on our previous high speed pipe extrusion line technology; with better structure calibrating and cooling become more effective.
  • high quality SS304; special surface teatment without problem of flaking paint.
 16mm×2.0mm PERT Pipe Extruder Machine Speed 50m/min For PERT Pipe Making

Haul-off Machine

  • Driven by servo motor with good stability, and speed chaning responding quite fast
  • low noise and less maintenance cost
 16mm×2.0mm PERT Pipe Extruder Machine Speed 50m/min For PERT Pipe Making

Winding Machine

  • Fully auto reel changing, pipe cutting for winding machine; with servo type traversing device
  • Auto strapping packaging device with auto discharging function are quoted as an operation
  • Pipe accumulator is equipped to ensure auto reel changing
  • Separate PLC control system
 16mm×2.0mm PERT Pipe Extruder Machine Speed 50m/min For PERT Pipe Making

CONTACT us to get clear video and more details!!
