Double Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide Bottle
Double Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide Bottle
Double Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide Bottle
Double Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide Bottle
Double Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide Bottle
Double Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide Bottle
Double Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide Bottle
Double Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide Bottle
Specifications
Brand Name :
MEPER
Model Number :
MP70D
Certification :
CE/ISO9001:2008
Place of Origin :
CHINA
MOQ :
1 set
Price :
Price negotiation
Payment Terms :
L/C, T/T
Supply Ability :
100 sets per month
Delivery Time :
25-35 work days
Packaging Details :
Standard export package, wooden pallet(standard) wooden case(optional)
Bottle :
1L Chemical Pesticide Bottle
Applicable Material :
HDPE LDPE PP PETG PVC PC PA EVOH EPET
Layer :
4 layer
Head :
2-3 heads
Product :
chemical bottle
Machine type :
Tie Bar type -D type
Description

4 Layer Double Station Extrusion Blow Molding Machine For 1L Chemical Pesticide Bottle

Introduction:

MP70D is specifically designed for making bottles from 50ml up to maximum 5L. It is hydraulic driven with accrate eletrical control system. MP70D has double stations to increase the production efficiency. Also, it has variety of choice of die heads. With more than 10 years of success in the market, MP70D is updated to be one of the most reliable and popular model in the world.

Advantages:

EXTRUSION DIE HEAD: HIGHLY EXPERIENCED MULTI-CAVITY AND MULTI-LAYER TECHNOLOGY

Adopting with latest die head design, MEPER focuses on providing high quality and high precision self-manufactured extrusion die heads for customers.

MP70D Double station blow molder with horizontal linear mould shuttle
Length: 3600mm

Double Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide Bottle
Width: 2200mm
Height 2360mm
Key Data MP70D
mm
Linear mould stroke A 450
Mould Width B 430
Mould Length C 350
Mould Thickness D 190
Opening Stroke E 290
Platen daylight D+E 480
Clamping Force 75kN
Dry Cycle 7 sec.
Centre Distance 2x2 fold 160
2x3 fold 120
2x4 fold 100
2x6 fold 60
Extruder φ70 φ75 φ80
Screw Speed r/min 0~65 0~65 0~65
Screw Diameter mm 70 75 80
Screw L/D Ratio L/D 24 24 24
Energy Requirements
Extruder Inverter Power kW 18.5 22 30
Extruder Moter Power kW 18.5 22 30
Srew Heating Power kW 12.7 14.4 15.85
Fan Power kW 0.14X2 0.14X2 0.14X2
Oil pump Motor Power kW 9.5 9.5 9.5
Total Power of Machine kW 49.14 54.34 63.79
Air Requirement approx m3/min 1.2 1.2 1.2
Air Working Pressure Mpa 0.6-0.8 0.6-0.8 0.6-0.8
Cooling Requirements
Consumption Cooling Water L/min 40 40 40

safety door device

The main function of Safety door is that preventing operator from entering into machine and putting hand into mould when mould platen is running.

Safety door installs obstructing shaft, limited sensor, stroke switch, which prevent people from entering into machine. limited sensor belongs to one kind of electric safe. When you close the door, it will contact sensor, then the clamping system works; when door is open, sensor doesn’t work, electric diagram is in a safe situation. stroke switch is also one kind of electric safe, when stroke switch is in a safe situation, if operator enter into door, then machine will give a alarm.

Double Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide Bottle

Double Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide BottleDouble Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide BottleDouble Station Extrusion Blow Molding Machine 4 Layer For 1L Chemical Pesticide Bottle
