6061 Anti Peeling Off Anodizing Aluminum Window Frame Extrusions
6061 Anti Peeling Off Anodizing Aluminum Window Frame Extrusions
6061 Anti Peeling Off Anodizing Aluminum Window Frame Extrusions
6061 Anti Peeling Off Anodizing Aluminum Window Frame Extrusions
6061 Anti Peeling Off Anodizing Aluminum Window Frame Extrusions
6061 Anti Peeling Off Anodizing Aluminum Window Frame Extrusions
Specifications
Brand Name :
Huilv
Model Number :
HL
Certification :
ISO9001 , ISO14001
Place of Origin :
China
MOQ :
300Kg
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50 000 Tons/Year
Delivery Time :
5-15 working days
Packaging Details :
inner protection film stick on each profile, outter a bundle packed by the carton or shrink paper.
Product Name :
China OEM ODM anti peeling off anodizing aluminum extrusion profiles for windows and doors
Material :
6063 6061 T5-T6
Shape :
square,tube, special shape or customized
Application :
window & door
Type :
OEM & ODM
Standard :
GB/T5237-2017
Production processes :
Design,extrusion,surface treatment
Colors :
According to your sample
Payment :
TT, LC
Die/mold making :
7-10 days
Description

Products Description:

Application

Aluminum construction (window and door / wall curtain)

Material

Alloy 6061 / 6063, We will never use aluminum scrap

Temper

T3-T8

Surface Treatment

Mill-Finished, Anodizing, Powder Coating, PVDF, Electrophoresis, Wood Grain, Polishing, Brushing, etc

Alloy or Not

Is Alloy

Length

3.0-7.2 Meters or Customized

Thickness

0.8mm-2.0mm or Customized
Profile type

1. Sliding window and door profiles
2. Casement window and door profiles
3. Louver window and door profiles
4. Bi-fold window and door profiles
5. Pivot window and door profiles
6. Awning window profiles
7. Heating insulation / thermal break profiles
8. Wall curtain profiles

Shape

Various shapes, parameters and colors available

Design

OEM or ODM is available, please send us your drawing

Aluminium Alloy: 6063, 6061, 6005, 6060 Thermal Treatment: T5-T6

Alloy Si Fe Cu Mn Mg Cr Zn Ti Other Impurity Al
Unit Total
6063 (0.2-0.6)% <0.35% <0.1% <0.1% (0.45-0.9)% <0.1% <0.1% <0.1% <0.05% <0.15% all the rest
6061 (0.4-0.8)% 0.7% (0.15-0.4)% <0.15% (0.8-1.2)% (0.04-0.35)% <0.25% <0.15% <0.05% <0.15% all the rest
6005 (0.6-0.9)% <0.35% <0.1% <0.1% (0.4-0.9)% 0.1% <0.1% <0.1% <0.05% <0.15% all the rest
6060 (0.3-0.6)% (0.35-0.6)% (0.1-0.3)% <0.1% <0.1% <0.15% <0.05% <0.1% <0.05% <0.15% all the rest

T5: After extruding aluminum profiles from the extruder, the temperature is rapidly reduced by air cooling to meet the required hardness (8 to 12 degrees Webster).

T6: After extruding aluminum profiles from the extruder, then cooled by water to achieve higher hardness (over 13.5 Webster’s).

6061 Anti Peeling Off Anodizing Aluminum Window Frame Extrusions

6061 Anti Peeling Off Anodizing Aluminum Window Frame Extrusions

6061 Anti Peeling Off Anodizing Aluminum Window Frame Extrusions

Production Line:

1. Extrusion Line

2. Wood Transfer Line

3. Powder Coating Line

4. Anodize Line

5. Polish Line

6061 Anti Peeling Off Anodizing Aluminum Window Frame Extrusions

Order Process:

1. Drawing/colours/price confirmed

2. Die/Mould Making (7 to 10 days)

3. Samples for your comfirmation(1 to 4 days)

4. Mass production,after receive 30% deposit (15 to 20days)

5. Customer check before shipping or SGS checking

6. Pay the balance and we loaded the container
