Plastic Bottle Cap Slitting Machine High Speed Full Automatic 1800*1650*1450
Plastic Bottle Cap Slitting Machine High Speed Full Automatic 1800*1650*1450
Specifications
Brand Name :
U TECH
Model Number :
BST-5
Certification :
CE SGS
Place of Origin :
China
MOQ :
1 sets
Price :
discussiable
Payment Terms :
L/C, T/T
Supply Ability :
20sets per hour
Delivery Time :
25-30days
Packaging Details :
wooden case
Type :
cap lip slitting folding machine
Dimension(l*w*h) :
1800*1650*1450
Condition :
New
Voltage :
220V/380V
Weight :
400kg
Warranty :
2 Years
Computerized :
Yes
After-sales service provided :
Engineers available to service machinery overseas
Power(w) :
2kw
Speed :
150-200cps per hour
Description

New Design high speed automatic plastic bottle cap slitting machine

The Slitting machine is designed and developed to provide security ring cutting for security caps. This machine is equipped with a series of all-auto technological processes, such as automatically putting cap in proper position, delivering cap, notching cap, disengaging caps, etc.

Full-Automatic High Speed Cap slitting machine for cutting caps to form tamper evident band

Production: We will be according to your cap shape to design the cap slitting machine include the slider,

die heads, holder and sorting bin.

Production capacity(30x20size) 15000-18000caps/hour for 2die heads

25000-30000pcs/hour for 4die heads

35000-40000pcs/hour for 6die heads

Installed electrical power:4kw(50hz/60hz)

Absorbed electrical power(appr.):0.6kw

Compressed air consumption: 80-120NL/min

Slitting machine specification
Type LT-28 Total power 0.7KW
Cap diameter 18mm-60mm Supply voltage 220V,50Hz
Cap height 12mm-50mm Compressed air consumption 0.5m³/min
Capacity 15000-20000pcs/hr Machine weight 160KG
Installed electrical power 1KW Size(L*W*H) 1700mm*700mm*1250mm

TERMS
PRICE TERMS EXW price
PAYMENT TERMS T/T 30% for deposit,70%balance after BUYER approve all the machine and before shipment
DELIVERY

Upon receipt of deposit, all machines need 50-55

working days to be completed.
PACKING Standard Sea Shipping Packing
GUARANTEE During normal operation, 18 months guarantee period is valid for all machines.

AFTER-SALES

SERVICE

• When the above listed machines are completed, the Buyer shall dispatch their qualified engineers to inspect their machines in manufacturer’s factory. The produced plastic caps from these machines should be checked against with the samples which given

by the Buyer before, and inspect approval by buyer.

• When the inspection, testing is done, the Seller will ship machines ASAP.

• Upon arrival of the machines at the Buyer’s factory, the Seller shall dispatch an engineer to the Buyer’s factory to install, debug the machines until all machines can produce qualified plastic caps. And the engineer also should train their technician to operate machine.

• Engineer’s tour including round-trip air tickets, lodging, boarding and transportation will be borne by the Buyer.

• Time for installation and debugging in Buyer’s factory: 5-7DAYS
