20 30 Litre PE Jerry Can Plastic Bottle Blow Molding Machine 37kw Low Noise
20 30 Litre PE Jerry Can Plastic Bottle Blow Molding Machine 37kw Low Noise
20 30 Litre PE Jerry Can Plastic Bottle Blow Molding Machine 37kw Low Noise
20 30 Litre PE Jerry Can Plastic Bottle Blow Molding Machine 37kw Low Noise
20 30 Litre PE Jerry Can Plastic Bottle Blow Molding Machine 37kw Low Noise
20 30 Litre PE Jerry Can Plastic Bottle Blow Molding Machine 37kw Low Noise
Specifications
Brand Name :
U TECH
Model Number :
BST-20
Certification :
CE SGS ISO
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1 Set/Sets
Price :
discussible
Payment Terms :
L/C, T/T
Supply Ability :
15 Set/Sets per Month
Delivery Time :
45 work days
Packaging Details :
Wooden Case for 5L-10L-15L-20L HDPE Plastic Jerry Can Tank Container Drum Extrusion Blowing Mould /Blow Molding Machine
Material :
Stainless Steel
PLC :
MITSUBISHI
Control System :
PLC+touch Screen
Warranty :
2 Years
Screw Diameter :
75mm
Plasticizing Capacity :
90kg/h
Max Mould Size :
600x500mm
Average Power Consumption :
37kw
Description

20 30 Litre PE Jerry Can Plastic Bottle Blow Molding Machine 37kw Low Noise
Introduction

Bottles & Jerry Can Making Machine BST-20 is single station blow moulding machine for 15L as maximum, specially used for 20L stackable jerry cans and containers. With single head for 20L jerry cans, with double head for 1~5L bottles. SRB75S is popular due to its wide products range, also suitable for small sized abnormal shaped hollow products, high quality and price rate, stable working performance, easy operation and maintenance.

Features & Advantages

1. Reasonable structure design and solid frame manufacturing to insure running stability.

2. Good head material runner deisgn and precision metal process for changing color easily.

3. According to your specified request, our machine can be made with co-extrusion of 1~3 layers and view stripe line.

4. Colorful touch screen, cantilever operation box, energy saving servo motor, robot arm and safety protection.

5. Total machine control system well match with pushing-out, core in/out, sub-mould de-molding, angle adjustable blowing unit, neck trimming tool, in-mould labeling, weight testing and leakage testing, product conveying & packing.

Parameter

SPECIFICATIONS & TECHNICAL DATA

Extrusion Unit

Screw Diameter

mm

75

Plasticizing Capacity

Kg/hour

90

Temperature Control Zone

No.

5

Continuous Head

Single Head Max Die Diameter

mm

230

Double Head Central Distance

mm

230

Triple Head Central Distance

mm

160

Four Head Central Distance

mm

120

Clamping Unit

Clamping Force

KN

180

Platen Size

mm

500x550

Opening Distance

mm

250~750

Moving Distance

mm

560

Max Mould Size

mm

600x500

Driving System

Extrusion Motor Power

KW

30

Pump Motor Power

KW

11

Machine Total Power

KW

72

Average Power Consumption

KW

37
