Automatic 20 Litre Pc Plastic Drum Water Tank Extrusion Moulding Blow Molding Machine
Automatic 20 Litre Pc Plastic Drum Water Tank Extrusion Moulding Blow Molding Machine
Automatic 20 Litre Pc Plastic Drum Water Tank Extrusion Moulding Blow Molding Machine
Automatic 20 Litre Pc Plastic Drum Water Tank Extrusion Moulding Blow Molding Machine
Automatic 20 Litre Pc Plastic Drum Water Tank Extrusion Moulding Blow Molding Machine
Automatic 20 Litre Pc Plastic Drum Water Tank Extrusion Moulding Blow Molding Machine
Automatic 20 Litre Pc Plastic Drum Water Tank Extrusion Moulding Blow Molding Machine
Automatic 20 Litre Pc Plastic Drum Water Tank Extrusion Moulding Blow Molding Machine
Specifications
Brand Name :
U TECH
Model Number :
BST-20
Certification :
CE SGS ISO
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1 Set/Sets
Price :
discussible
Payment Terms :
L/C, T/T
Supply Ability :
15 Set/Sets per Month
Delivery Time :
45 work days
Packaging Details :
Wooden Case for 5L-10L-15L-20L HDPE Plastic Jerry Can Tank Container Drum Extrusion Blowing Mould /Blow Molding Machine
Material :
Stainless Steel
PLC :
MITSUBISHI
Control System :
PLC+touch Screen
Warranty :
2 Years
Screw Diameter :
75mm
Plasticizing Capacity :
90kg/h
Max Mould Size :
600x500mm
Average Power Consumption :
37kw
Description

Automatic 20 Litre Pc Plastic Drum Water Tank Extrusion Moulding Blow Molding Machine

Introduction

BST20 auto extrusion blow molding machine was specially designed for making plastic water tanks,plastic cans, lubricant oil bottles,plastic drums, plastic toys and other plastic containers not over 20L.

Extrusion blow molding machine is suitable for producingPP/PE/PU/PC/PVC/PETG/HDPE/LDPE/ABS/..... plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc. Beverage bottle, cosmetic bottle, medicine bottle, jar etc.

The features of this machine:

(1) It is suitable for producing PE,HDPE,PP, PVC so on,plastic containers and bottles in all shapes are available,the max.product volume is up to 20L.

(2) Single station single die head design,very easy to operate and maintenance.

(3) Most components of the blow moulding machine are from famous world brand.

(4) Fully automatic process with low power consumption,high efficiency,quick and safe operation,easy for maintenance.

(5) Multiple screw available for double layer or tranparent liquid lever line.

(6) Auto deflashing device available,can remove the extra parts of bottles.

(7) Auto lubricant system controlled by PLC.

Parameter

SPECIFICATIONS & TECHNICAL DATA

Extrusion Unit

Screw Diameter

mm

75

Plasticizing Capacity

Kg/hour

90

Temperature Control Zone

No.

5

Continuous Head

Single Head Max Die Diameter

mm

230

Double Head Central Distance

mm

230

Triple Head Central Distance

mm

160

Four Head Central Distance

mm

120

Clamping Unit

Clamping Force

KN

180

Platen Size

mm

500x550

Opening Distance

mm

250~750

Moving Distance

mm

560

Max Mould Size

mm

600x500

Driving System

Extrusion Motor Power

KW

30

Pump Motor Power

KW

11

Machine Total Power

KW

72

Average Power Consumption

KW

37
