Traffic Fence Fully Automatic Blow Moulding Machine 160L Auto Blowing Machine
Traffic Fence Fully Automatic Blow Moulding Machine 160L Auto Blowing Machine
Traffic Fence Fully Automatic Blow Moulding Machine 160L Auto Blowing Machine
Traffic Fence Fully Automatic Blow Moulding Machine 160L Auto Blowing Machine
Traffic Fence Fully Automatic Blow Moulding Machine 160L Auto Blowing Machine
Traffic Fence Fully Automatic Blow Moulding Machine 160L Auto Blowing Machine
Traffic Fence Fully Automatic Blow Moulding Machine 160L Auto Blowing Machine
Traffic Fence Fully Automatic Blow Moulding Machine 160L Auto Blowing Machine
Specifications
Brand Name :
SHUANGLI
Model Number :
SLBC-110
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Price negotiation.
Payment Terms :
L/C, T/T
Supply Ability :
100 Set per month
Delivery Time :
20 woking day
Packaging Details :
Standard export package
Material :
PE,PP,EVA,ABS,PS
Max capacity :
160L
Station :
Single
Product :
Plastic traffic Fence
Type :
Accumulator Type
Die Head :
1 Head
Description

Accumulator Type Single Station 1 Die Head Plastic Blow Molding Machine For Plastic traffic Fence

SLBC series: (German model)

1: linear guide support single frame, finite element analysis of the design, to ensure adequate clamping force, not up mode.the whole system is equipped with safety protection grating, to ensure the safety of the production process. With friendly PLC .

2: large opening stroke, central locking, locking force equilibrium, no deformation.All parts of the machine is made by advanced numerical control equipment with high precision.

3: high accuracy without the fusion line storage type die head, easy to change color, with servo walll thickness control

system, improve product quality, reduce production costs.

4: optional with multi function under blowing mechanism, automatic machine to take the product of a variety of auxiliary

device, realize the production process is highly automated.

SPECIFICATION SLBC-110
MATERIAL 　 PE,PP,EVA,ABS,PS
MAX CONTAINER CAPACITY L 160
OUPUT(DRY CYCLE) PC/HR 360
MACHINE DIMENSION (LxWxH ) MM 7500x3600x5800
TOTAL WEIGHT TON 20T
CLAMPING UNIT 　
CLAMPING FORCE KN 680
PLATEN OPENING STROKE MM 600-1400
PLATEN SIZE(WxH) MM 1400x1600
MAX MOULD SIZE(WxH) MM 1200x1900
MOLD THICKNESS MM 610-880
EXTRUDER UNIT 　
SCREW DIAMETER MM 110
SCREW L/D RATIO L/D 25
MELTING CAPACITY KG/HR 220
BARREL HEATING POWER KW 36
NUMBER OF HEATING ZONE ZONE 6
EXTRUDER MOTOR RATED POWER KW 75
DIE HEAD 　
NUMBER OF DIE HEATING ZONE ZONE 5
POWER OF DIE HEATING KW 35
MAX DIE-PIN DIAMETER MM 550
POWER 　
MAX DRIVE POWER KW 120
TOTAL POWER KW 130
FAN POWER OF SCREW KW 4.8
AIR PRESSURE MPA 0.8-1.2
AIR CONSUMPTION M3/MIN 0.8
AVERAGE ENERGY CONSUMPTION KW 56
ACCUMULATOR CAPACITY L 20

Traffic Fence Fully Automatic Blow Moulding Machine 160L Auto Blowing Machine
