High Speed Double Station Blow Molding Machine 1 Head Agriculture Bottle Extrusion
High Speed Double Station Blow Molding Machine 1 Head Agriculture Bottle Extrusion
High Speed Double Station Blow Molding Machine 1 Head Agriculture Bottle Extrusion
High Speed Double Station Blow Molding Machine 1 Head Agriculture Bottle Extrusion
High Speed Double Station Blow Molding Machine 1 Head Agriculture Bottle Extrusion
High Speed Double Station Blow Molding Machine 1 Head Agriculture Bottle Extrusion
High Speed Double Station Blow Molding Machine 1 Head Agriculture Bottle Extrusion
High Speed Double Station Blow Molding Machine 1 Head Agriculture Bottle Extrusion
Specifications
Brand Name :
SHUANGLI
Model Number :
SLBU-65
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Price negotiation.
Payment Terms :
L/C, T/T
Supply Ability :
100 Set per month
Delivery Time :
20 woking day
Packaging Details :
Standard export package
Material :
PE,PP,EVA,ABS,PS
Max capacity :
5L
Product :
Plastic Agriculture Bottle
Machine Type :
U type
Layer :
2 Layers
Station :
Double
Description

High Speed 2 Layer Double Station 1 Die head Blow Molding Machine for Plastic Agriculture Bottle

1: this machine is suitable for the production of 200ML -5L plastic hollow products,

2: Servo Hydraulic System includes Servo Head Lifting, Servo Die Head, Servo Parison Control System, Servo Blow Pin, Servo Clamping Unit and Servo Carriage'

3 As long as the value of each segment of the current temperature value is clicked in the temperature parameter setting screen, the temperature trend graph of each segment will be automatically popped up, which reflects the fluctuation of each segment of the temperature during the heating process, and can be adjusted according to the change of the trend graph. The PID parameters for each temperature control, which makes the heating temperature more correct. Click the "Back" button to enter the temperature parameter setting screen.

SPECIFICATION SLBU-65
MATERIAL 　 PE,PP,EVA,ABS,PS
MAX CONTAINER CAPACITY L 5
NUMBER OF DIE HEAD SET 1,2,3,4,6,8
OUPUT(DRY CYCLE) PC/HR 1000x2
MACHINE DIMENSION (LxWxH ) MM 4000x2300x2200
TOTAL WEIGHT TON 6.5T
CLAMPING UNIT 　
CLAMPING FORCE KN 65
PLATEN OPENING STROKE MM 220-520
PLATEN SIZE(WxH) MM 400x430
MAX MOULD SIZE(WxH) MM 460x430
MOLD THICKNESS MM 255-280
EXTRUDER UNIT 　
SCREW DIAMETER MM 65
SCREW L/D RATIO L/D 25
MELTING CAPACITY KG/HR 70
BARREL HEATING POWER KW 15
NUMBER OF HEATING ZONE ZONE 3
EXTRUDER MOTOR RATED POWER KW 15
DIE HEAD 　
NUMBER OF DIE HEATING ZONE ZONE 2-5
POWER OF DIE HEATING KW 6
CENTER DISTANCE OF DOUBLE DIE MM 130
CENTER DISTANCE OF THREE DIE MM 110
CENTER DISTANCE OF FOUR DIE MM 100
CENTER DISTANCE OF SIX DIE MM 80
MAX DIE-PIN DIAMETER MM 180
POWER 　
MAX DRIVE POWER KW 18
TOTAL POWER KW 50
FAN POWER OF SCREW KW 2.4
AIR PRESSURE MPA 0.6
AIR CONSUMPTION M3/MIN 0.4
AVERAGE ENERGY CONSUMPTION KW 18

High Speed Double Station Blow Molding Machine 1 Head Agriculture Bottle Extrusion

High Speed Double Station Blow Molding Machine 1 Head Agriculture Bottle Extrusion
