Single Head Parison Jerry Can Blow Molding Machine 300bph For Plastic Bottle
Single Head Parison Jerry Can Blow Molding Machine 300bph For Plastic Bottle
Single Head Parison Jerry Can Blow Molding Machine 300bph For Plastic Bottle
Single Head Parison Jerry Can Blow Molding Machine 300bph For Plastic Bottle
Single Head Parison Jerry Can Blow Molding Machine 300bph For Plastic Bottle
Single Head Parison Jerry Can Blow Molding Machine 300bph For Plastic Bottle
Single Head Parison Jerry Can Blow Molding Machine 300bph For Plastic Bottle
Single Head Parison Jerry Can Blow Molding Machine 300bph For Plastic Bottle
Specifications
Brand Name :
SHUANGLI
Model Number :
SLBC-120
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Price negotiation.
Payment Terms :
L/C, T/T
Supply Ability :
100 Set per month
Delivery Time :
20 woking day
Packaging Details :
Standard export package
Material :
PE,PP,EVA,ABS,PS
Max capacity :
160L
Station :
Single
Product :
Plastic Jerry Can Oil Bottle
Die Head :
1 Head
Parison System :
Moog
Description

Single Station One Head Blow Molding Machine for Plastic Jerry CanOil Bottle with Parison System​

SLBC series: (German model)

1: optional with multi function under blowing mechanism, automatic machine to take the product of a variety of auxiliary

device, realize the production process is highly automated.And equipped with imported hydraulic, pneumatic and electrical parts of famous brand,

it has stable equipment performance and simple handling.with PLC SIEMENS.

2: blow molding machine

1)Before connecting the machine to the power supply, please make sure that the power supply is shut down.

2)Connect the cable to a three-phase power supply terminal.

3)Each machine should be earthed separately.

4)In order to make control system work well, please don’t let it share a power supply with other machines such as high frequency machines because the mixed wave produced by these machines will interfere the computer.

SPECIFICATION SLBC-120
MATERIAL 　 PE,PP,EVA,ABS,PS
MAX CONTAINER CAPACITY L 160
OUPUT(DRY CYCLE) PC/HR 300
MACHINE DIMENSION (LxWxH ) MM 7500x4200x6200
TOTAL WEIGHT TON 22T
CLAMPING UNIT 　
CLAMPING FORCE KN 800
PLATEN OPENING STROKE MM 600-1400
PLATEN SIZE(WxH) MM 1400x1600
MAX MOULD SIZE(WxH) MM 1200x1900
MOLD THICKNESS MM 610-880
EXTRUDER UNIT 　
SCREW DIAMETER MM 120
SCREW L/D RATIO L/D 25
MELTING CAPACITY KG/HR 280
BARREL HEATING POWER KW 42
NUMBER OF HEATING ZONE ZONE 6
EXTRUDER MOTOR RATED POWER KW 90
DIE HEAD 　
NUMBER OF DIE HEATING ZONE ZONE 5
POWER OF DIE HEATING KW 38
MAX DIE-PIN DIAMETER MM 500
POWER 　
MAX DRIVE POWER KW 125
TOTAL POWER KW 180
FAN POWER OF SCREW KW 4.8
AIR PRESSURE MPA 0.8-1.2
AIR CONSUMPTION M3/MIN 0.8
AVERAGE ENERGY CONSUMPTION KW 72
ACCUMULATOR CAPACITY L 30
