160l Accumulator Blow Moulding Machine Single Station ABS Water Tank
160l Accumulator Blow Moulding Machine Single Station ABS Water Tank
160l Accumulator Blow Moulding Machine Single Station ABS Water Tank
160l Accumulator Blow Moulding Machine Single Station ABS Water Tank
160l Accumulator Blow Moulding Machine Single Station ABS Water Tank
160l Accumulator Blow Moulding Machine Single Station ABS Water Tank
160l Accumulator Blow Moulding Machine Single Station ABS Water Tank
160l Accumulator Blow Moulding Machine Single Station ABS Water Tank
Specifications
Brand Name :
SHUANGLI
Model Number :
SLBC-120
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Price negotiation.
Payment Terms :
L/C, T/T
Supply Ability :
100 Set per month
Delivery Time :
20 woking day
Packaging Details :
Standard export package
Material :
PE,PP,EVA,ABS,PS
Max capacity :
160L
Station :
Single
Die Head :
1 Head
Product :
Plastic Water Tank
Parison :
B&R
Description

Single Station One Head Blow Molding Machine for Plastic Water Tank with Parison System

SLBC series: (German model)

1: (1) Steps of filling hydraulic oil

Uncover the cap of the oil tank and fill proper hydraulic oil until the oil level reaches the top point of the oil-level gauge. The oil level in the oil tank

will decline due to every cylinder and pipeline will be full of oil after the first running of the machine, hydraulic oil should be added at this time to

keep the oil level above the oil scale.


Note:

(a) Please don’t mix hydraulic oil and lubricant of different product names.

(b) Starting the oil pump is not allowed within three hours after filling hydraulic oil into oil tank, to make sure the gas in the hydraulic oil can be removed.

2: the whole system is equipped with safety protection grating, to ensure the safety of the production process without acciden.with PLC SIEMENS.

SPECIFICATION SLBC-120
MATERIAL 　 PE,PP,EVA,ABS,PS
MAX CONTAINER CAPACITY L 160
OUPUT(DRY CYCLE) PC/HR 300
MACHINE DIMENSION (LxWxH ) MM 7500x4200x6200
TOTAL WEIGHT TON 22T
CLAMPING UNIT 　
CLAMPING FORCE KN 800
PLATEN OPENING STROKE MM 600-1400
PLATEN SIZE(WxH) MM 1400x1600
MAX MOULD SIZE(WxH) MM 1200x1900
MOLD THICKNESS MM 610-880
EXTRUDER UNIT 　
SCREW DIAMETER MM 120
SCREW L/D RATIO L/D 25
MELTING CAPACITY KG/HR 280
BARREL HEATING POWER KW 42
NUMBER OF HEATING ZONE ZONE 6
EXTRUDER MOTOR RATED POWER KW 90
DIE HEAD 　
NUMBER OF DIE HEATING ZONE ZONE 5
POWER OF DIE HEATING KW 38
MAX DIE-PIN DIAMETER MM 500
POWER 　
MAX DRIVE POWER KW 125
TOTAL POWER KW 180
FAN POWER OF SCREW KW 4.8
AIR PRESSURE MPA 0.8-1.2
AIR CONSUMPTION M3/MIN 0.8
AVERAGE ENERGY CONSUMPTION KW 72
ACCUMULATOR CAPACITY L 30

160l Accumulator Blow Moulding Machine Single Station ABS Water Tank
