30l Accumulator Blow Moulding Machine Single Head 600bph Plastic Blowing Machine
30l Accumulator Blow Moulding Machine Single Head 600bph Plastic Blowing Machine
30l Accumulator Blow Moulding Machine Single Head 600bph Plastic Blowing Machine
30l Accumulator Blow Moulding Machine Single Head 600bph Plastic Blowing Machine
30l Accumulator Blow Moulding Machine Single Head 600bph Plastic Blowing Machine
30l Accumulator Blow Moulding Machine Single Head 600bph Plastic Blowing Machine
30l Accumulator Blow Moulding Machine Single Head 600bph Plastic Blowing Machine
30l Accumulator Blow Moulding Machine Single Head 600bph Plastic Blowing Machine
Specifications
Brand Name :
SHUANGLI
Model Number :
SLBC-80
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Price negotiation.
Payment Terms :
L/C, T/T
Supply Ability :
100 Set per month
Delivery Time :
20 woking day
Packaging Details :
Standard export package
Material :
PE,PP,EVA,ABS
Max capacity :
30L
Product :
Plastic Parts
Clamping Type :
Tie Bar
Station :
Single
Description

1 Die Head Accmulator Type Single Station Plastic Blow Molding Machine For Plastic Parts

SLBC series: (German model)

machine is suitable for producing plastic products of PE/PP/EVA/ABS/K material TPU, nylon and other materials . All parts of the machine is

made by advanced numerical control equipment with high precision. And equipped with imported hydraulic, pneumatic and electrical parts of

famous brand, it has stable equipment performance and simple handling.

Since the mold shifting and opening and closing mechanism are frequently operated and the moving speed is fast, an automatic lubricating

device is disposed, but the lubricating oil in the automatic lubricating device is also regularly inspected and filled. This will increase and extend

the life of the machine, resulting in better economics. The movement mode of the mold shifting and opening and closing mold mechanism is fast,

and it is necessary to pay great attention to safety during the installation of the mold, the debugging, and the adjustment process, especially

when the two templates and the two sides of the mold shifting seat are in operation, please keep away from the safety.

SPECIFICATION SLBC-80
MATERIAL 　 PE,PP,EVA,ABS,PS
MAX CONTAINER CAPACITY L 30
OUPUT(DRY CYCLE) PC/HR 600
MACHINE DIMENSION (LxWxH ) MM 5300x3000x3500
TOTAL WEIGHT TON 11T
CLAMPING UNIT
CLAMPING FORCE KN 200
PLATEN OPENING STROKE MM 350-850
PLATEN SIZE(WxH) MM 750x780
MAX MOULD SIZE(WxH) MM 600x1000
MOLD THICKNESS MM 360-500
EXTRUDER UNIT
SCREW DIAMETER MM 80
SCREW L/D RATIO L/D 25
MELTING CAPACITY KG/HR 120
BARREL HEATING POWER KW 16
NUMBER OF HEATING ZONE ZONE 4
EXTRUDER MOTOR RATED POWER KW 30
DIE HEAD
NUMBER OF DIE HEATING ZONE ZONE 4
POWER OF DIE HEATING KW 15
MAX DIE-PIN DIAMETER MM 250
POWER
MAX DRIVE POWER KW 42
TOTAL POWER KW 82
FAN POWER OF SCREW KW 3.2
AIR PRESSURE MPA 0.8-1.2
AIR CONSUMPTION M3/MIN 0.8
AVERAGE ENERGY CONSUMPTION KW 32
ACCUMULATOR CAPACITY L 6
