Specifications
Brand Name :
Aorui
Model Number :
SJSZ65x132
Certification :
CE UL CSA ISO9001
Place of Origin :
ShanDong China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T L/C
Supply Ability :
10 sets per month
Delivery Time :
30 days
Packaging Details :
Fumigation wood, film,pallet,etc or according to customer’s requirement.
Original :
Shandong , China
Automatic Grade :
Fully automatic
Screw&Barrel material :
38Cr MOAIA
Type of extruder :
Twin screw extruder
Delivery time :
30 days
Voltage :
380V 50HZ
Warranty :
1 year
Description

PVC Fiber Reinforced Soft Pipe Extrusion Line / pvc Fiber Reinforced Hose Extruder Production Line

Description of pvc fiber reinfoced pipe production line:

1. This line is designed to produce PVC fiber reinforced hose,the wall of which is three layers,outer and inner layer are soft PVC hose,middle layer is Terlene fiber network,which has good chemical and physical property,it is mainly used for the transportation of high pressure or corrosive gas,and is widely used in the machinery,coal mine,chemical,agriculture irrigation,gas and building.

2. pvc fiber reinforced soft pipe making machine/extrusion line : Process flow

PVC powder + additive --- mixing---spring feeder---twin screw extruder---mould and calibrator---vacuum forming machine---haul-off machine---cutting machine---discharge rack

3. PVC fiber reinforced pipe production line has a good market in worldwide. We can supply PVC fiber reinforced hose production line with competitive price and high quality.

Technical parameters of pvc fiber reinforced pipe machinery:

Model Extrusion type Screw diameter
(mm)		 Pipe range
(mm)

Capacity
(kg/h)

 Main motor power
(kw)		 Line length
(m)
GF40 Double-out 51/105 16-40 80-120 18.5 22
GF63 Double-out 65/132 16-63 120-250 37 25

Application:

PVC fiber reinforced hose production line is mainly used to manufacture fiber-reinforced hose for fluid conveying.PVC fiber reinforced pipe can be used as pipelines to conveying air, water, gas, oil and other kind of fluid and gas.

Our machine's advatanges:

1. High output

2. high performance

3. operation stable

Soft Pvc Fiber Reinforced Hose Plastic Extrusion Line / Twin Screw Extruder Production Line
