Single Screw PE Pipe Extrusion Line , PE Pipe Machine For PE Water Pipe Production
Single Screw PE Pipe Extrusion Line , PE Pipe Machine For PE Water Pipe Production
Single Screw PE Pipe Extrusion Line , PE Pipe Machine For PE Water Pipe Production
Single Screw PE Pipe Extrusion Line , PE Pipe Machine For PE Water Pipe Production
Single Screw PE Pipe Extrusion Line , PE Pipe Machine For PE Water Pipe Production
Single Screw PE Pipe Extrusion Line , PE Pipe Machine For PE Water Pipe Production
Single Screw PE Pipe Extrusion Line , PE Pipe Machine For PE Water Pipe Production
Single Screw PE Pipe Extrusion Line , PE Pipe Machine For PE Water Pipe Production
Specifications
Brand Name :
AORUI
Model Number :
SJ90/33
Certification :
CE & ISO9001
Place of Origin :
ShanDong China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T L/C
Supply Ability :
30 sets per quarter
Delivery Time :
30 days
Packaging Details :
Fumigation wood, film,pallet,etc or according to customer’s requirement.
Condition :
New
Screw Number :
One
Machine name :
PE Pipe making machine
Trade mark :
Aorui
Frequency control :
ABB
Certificate :
CE ISO9001
Payment terms :
TT or L/C
Temperature control :
Omron
Description

PE Pipe Production Line , PE Ppe Extrusion Line , PE Pipe Extruder

Quick detail

1.This pe pipe machine can produce pipe with different diameter.

2.Pipe diameter from 16-630mm.Different pipe diameter has different model.

3.PE PP PPR pipe Making line is consisted of extruder, vacuum calibrator, hauling machine,cutter and tipping rack, hauling machine unit has come ways of hauling, such as caterpillar type, three-claw type, four-claw type, six-claw type and so on. There are also knife-lifting cutter and planetary cutter.

4.This ppr pe pipe machine has such characteritics: High efficiency, high output, cost save etc.


Description:


1.The entire production line USES proprietary sizing and cooling systems,adopt water film lubrication and water ring cooling,to meet the requirements of pp PE material, to ensure that the high-speed production of thick-walled tube is stable in diameter and roundness.
2.The vacuum sizing box with multi-stage vacuum degree control is specially designed to ensure the dimension stability and roundness of pp PE pipe.

3.PLC is adopted for programmed control, with good man-machine interface, and all process parameters can be set and displayed through touch screen. Special extruder for marking line can be assembled to produce tubes with color marking line in line with national standards.


Feartures of PE Pipe Production Line:

HDPE PE tube pipe making extrusion machine
a) Highly automatic
b) Even plasticization

Main Technical Parameters:

Model ParametersLGSJ-110LGSJ-130LGSJ-150LGSJ-180LGSJ-210
Screw diameter (mm)110130150180210
Screw length(mm)20002200240026002800
Machine power(kw)2230374555
screw rotate speed (r/min)55-6050-5545-5040-4535-40
Changer motor power(kw)1.51.51.51.52.2
Production capacity(kg/h)80100150200250
Matched pelleter power (kw)1.11.11.11.12.2
Matched crusher/washer power (kw)18.5/7.518.5/7.522/1130/1537/18.5
Crusher & washers production capacity (kg/h)400450500600600
3+1PH380V50HZ PC Machine installed power6080100120140


Machine Display:

Single Screw PE Pipe Extrusion Line , PE Pipe Machine For PE Water Pipe Production
