Specifications
Brand Name :
Aorui
Model Number :
SJSZ65/132
Certification :
CE UL CSA ISO9001
Place of Origin :
ShanDong China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T L/C
Supply Ability :
10 sets per quarter
Delivery Time :
30 days
Packaging Details :
Fumigation wood, film,pallet,etc or according to customer’s requirement.
Condition :
New
Screw Design :
Double screw
Automatic grade :
Fully automatic
Certificate :
CE ISO9001
Voltage :
380V 50HZ
Warranty :
1 year
Motor brand :
Siemens
Description

Plastic Profile Extrusion Line , PVC WPC Window and Door Profile Extruder

Description of pvc wpc profile extrusion line:

1.Production flow of PVC window door and door profile:
Material mixing, extruding, molding, vacuum calibrating and cooling, hauling, cutting- final PVC profiles

2.The main machines needed for PVC profile:
-Mixer
-PVC profile extrusion line (Including autoloader, conical twin screw extruder, mould, vacuum calibration platform, hauling machine, auto cutter- stacker)
- Lamination machine (wrapping machine)
- PVC crusher& PVC miller
- Air compressor
- Water chiller (optional)

3.Wood-Plastic Co-extrusion(foamed) Profile Production Line

There is no need for unit granulation; the material mixed with wood flour can be directly extruded wood-plastic profile.

Main Technical Parameters:

Production Line Model YF180 YF240 YF300
Maximum profile width (mm) 180 240 300
Auxiliary total power (kw) 18.7 27.5 33.1
Cooling water capacity (m3/h) 5 7 7
Compressed air pressure (MPa) 0.6 0.6 0.6

Application of wpc profile production line:

It's used to produce PVC profiles with different shape and size for PVC window, door etc,

such as casement series PVC profile, sliding series PVC profile.

Our pvc machine advantages:

1.High Production Capacity , Stable production, easy maintenance, long service life.

2.High Precision : Thickness Can Be Adjusted, Tolerance Between 0.05mm-0.1mm.

3.Veriaty Styles : Shapes And Sizes Can Be Customized According To Requirements.

4. Low Energy Consumption : Frequency Converter Can Save Power.

5. Convenient Operation : It’s Easy To Operate.
