Specifications
Brand Name :
Desu
Place of Origin :
Guangdong, China
MOQ :
1 set
Price :
$30,000.00/Pieces 1-9 Pieces
Packaging Details :
Wooden packing
Model :
High Speed Intelligence Model Paper Cup Machine JBZ-OCM12
Paper Cup Size :
2~16 OZ(Mould exchangeable,Max Cup Height: 136mm,Max Bottom width: 76mm
Rated Speed :
75-85pcs/min (Speed affected by cup size,paper quality & thickness)9OZ,280GSM paper cup Stable running speed 80 pcs each min.
Raw Material :
One or Two side PE coated Paper(Popular for Hot and Cold drink Cups)
Power Source: :
50/60HZ,380V/220V(better use 380V,3 Phase)or special Power requirement.
Cup Bottom Knurling :
Heater Knurling(ifuse single PE coated paper)
Description

cup making machine paper cup forming paper cup lid making machine machine for making paper cupsServo Paper Container Making Machine High Speed Paper Cup Forming Machine

Machine model: high-speed simple paper cup machine
Backside Soldering : Copper Heater Ultrasonic Heater

Raw material : single side PE coated paper (popular hot drink cup) single/double PE coated paper (popular hot drink cup and cold drink cup)
Total weight : Gw /NW:1750 kgs/1650 KgS.
Working air source (ultrasonic): Air pressure 0.4MPa a. machine.
Cup bottom heating: heater knurling (single-sided PE paper is heated and knurled; double-sided PE paper is knurled with cooling device circular water.)
Bottom knurling: heat knurling (if using single layer PE coated paper)

Servo Paper Container Making Machine High Speed Paper Cup Forming Machine
Servo Paper Container Making Machine High Speed Paper Cup Forming Machine

Servo Paper Container Making Machine High Speed Paper Cup Forming Machine

Electric System:

High-quality brand electrical systems, such as Delta, Schneider.
The PLC control system adopts the Delta brand, which is made in Taiwan and is reliable.
quality.

Servo Paper Container Making Machine High Speed Paper Cup Forming MachineServo Paper Container Making Machine High Speed Paper Cup Forming Machine

Servo Motor:

The bttom paper feeding is controlled by servo motor and stepping motor,which greatly improve paper feeding in high precision and
high efiency way.(more stable ,less troubles and save bottom paper)
Servo Paper Container Making Machine High Speed Paper Cup Forming Machine

Paper size :

2~16 oz (replaceable die, max cup height 136mm, max bottom width 76mm.)

Rated speed:

70-80 per minute (the speed is affected by the size of the paper cup, paper quality and thickness), the running speed is stable, 75 per minute

Paper material:

140-250 GSM.140~350gsm.

Power requirements:

50/60 Hz.380V/220V (preferably use 380V, 3Phase) or special power requirements

Total power :

6.5 kw, 7.5 kw.

Total weight : Gw /NW:1750 kgs/1650 Kgs.


Servo Paper Container Making Machine High Speed Paper Cup Forming Machine

Excerpted from the Internet, for reference only"The paper cup is limited by the non waterproof property of the paper. In order to prevent water seepage, a plastic polyethylene (PE) coated film will be added to the paper cup." According to a person from a plastic packaging enterprise in Haikou, Hainan, hot drinks will be coated inside the cup, and cold drinks will be coated inside and outside the cup. It is not easy to separate from paper in the recycling process, so they are classified as non recyclable waste.
It is understood that since December 1 of last year, Hainan has comprehensively "banned plastic products", the production and sales of plastic products listed in the List of Prohibited Production, Sales and Use of Disposable and Non degradable Plastic Products in Hainan Province (the first batch) will be prohibited. The above companies have developed and produced plastic free paper cups with water-based coatings instead of traditional paper cups with polyethylene coatings to achieve full biodegradation.
Whether the plastic free paper cups produced by the enterprise are qualified or not is finally determined by the standard the final say. The group standard draft of Plastic free Paper Cup (including plastic free paper cup) pointed out that "the base paper of paper cup shall meet the requirements of QB/T 4032. The white oil shall meet the requirements of GB 1886.215. The ink and adhesive shall meet the requirements of relevant standards. The additives used for paper cup base paper, white oil, ink, adhesive and water-based paint shall meet the requirements of GB 9685."
