USB Pen Driver Weatherproof WG26 RFID Card Access Control
Metal Case RFID Card Access Control System IP68 Waterproof For Outdoor Use
Our factory covers an area of 2,500 Square meters with around 100 Employees, So far we have obtained the
verified vertificates, like ISO9001, CE, FCC, ROHS, etc. and achieved China's highest manufacturing honor
of "National High-tech Enterprise" in 2017 with more than 10 patents.
We had grown rapidly on our overseas operation since we formally established our own export department
in 2016. Each year we will make at least 7 times of business trip to join the exhibition or visit our clients in some
countries, We have two brand: " TIMMY" and new "TiMY". TiMY( TIMMY) does business cooperation with
worldwide friends through the advantages of High Quality Guarantee, Good Price Support, Professional technical
service team, Flexible OEM on Hardware& Software.
RFID Card Access Control Description:
◆ Backlight Touch Keypad
◆ Metal Case, Anti-vandal
◆ High Level Waterproof IP68 Standalone
◆ 2000 user high capacity for standalone access control device.
◆ Card Type: EM/MF
◆ Working Voltage: DC12-24V.
◆ Door Open Time:0-99s( adjustable)
◆ WG26 input/output
RFID Card Access Control Specification:
| Metal Case RFID Card Access Control System IP68 Waterproof For Outdoor Use | |
| Product Name | TIMMY TDS19 IP68 touch keypad waterproof RFID reader card access control system |
| Model | TDS19(Access Control Waterproof) |
| Working | Standalone |
| Identification Style | Keypad, ID card, Keypad+ID card(Optional IC card) |
| Communication | USB Line, USB Pen Driver |
| | <0.5 sec |
| FAR | <0.01 |
| FRR | <0.0001 |
| Card Capacity | 2000 cards/code in total |
| Size | 115*75*225mm |
| Working voltage | DC12V-24V |
| Keypad | Backlight touch keypad |
| Material | Metal Case, Anti-vandal |
| Protection grade | IP68 waterproof for outdoor use |
| Low power consumption | Static Current Less Than 30mA |
| Wiegand Output | 26/34 |
| Fast Response | Less than 0.1s for Door Relay Control |
| Direct Heypad Operation for Password, Card Registration and deletion |
RFID Card Access Control FAQ:
Q1: Are you are real factory:
Yes, our factory is based in Shenzhen China and we've been in this industry for 20 years.Timmy is a supplier of professional biometric recognition solutions.Our company has several different fairly proprietary pieces of technology
and a completed industrial chain including developing, producing, sales and after-sales service department, to promote its sustainable development.
Q2: Can we get free sample?
Reply: We are honored to offer you samples, you can send E-mail to us or contact us to require samples. It's convenient for you, so please do not hesitate to contact us if you need a sample.
Q3: How long is your warranty?
Normally warranty period is one year.
Q4: Can you print customer's logo?
Reply:No problem, Logo printed is free for order of more than 100pcs. OEM is acceptable.
Q5. What about after sales service about device using?
We have international technician team and we can have online communication via Skype, Whatsapp, Wechat or any other social media.
Standalone
