Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
Specifications
Brand Name :
FAIRY LED
Model Number :
FY-STD01
Certification :
CE RoHS
Place of Origin :
China
MOQ :
1pcs
Payment Terms :
T/T, D/A, T/T, D/A, D/P, Western Union, MoneyGram, Paypal
Supply Ability :
20,000pcs / month
Delivery Time :
7-10 days for <500pcs
Packaging Details :
neutral packing, or customized packing as per customers' requrements
Rated Power :
35W / 50W
Input Voltage :
100-277V, 50/60Hz
Luminous Efficiency :
110Lm/W
Light Source :
high quality 2835SMD
Driver Type :
constant-current LED driver
PF :
>0.9
Dimension: :
285*100mm
Material :
die-casting aluminum body + PC cover
Protection Grade :
IP65 waterproof
Photocell :
available
PIR sensor :
available
Warranty :
5 years
Description

Dusk To Dawn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor

Product Features:

  • Universal voltage AC100-277V, 50/60Hz
  • 110Lm/W for fixture
  • Using high quality SMD2835 chips
  • Constant current power supply
  • High power factor >0.9, low THD driver.
  • Constructed from die-casting aluminum, with a PC cover, and rated at IP65.
  • Respirator design: balance the different pressure between the atmosphere and the shell. It is waterproof and also defog and avoiding the drop condensation, extend the product lifespan.
  • 5 years warranty.
  • Available with Photocell or PIR sensor.

Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
Drawing:
Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
Parameters:

ItemModelFY-STD01-35WFY-STD01-50W
General PerformancePower35W50W
Lumen Output3850Lm5500Lm
Efficacy110Lm/W110Lm/W
CCT2700K-6500K2700K-6500K
LED TypeSMD 2835SMD 2835
CRIRa>80Ra>80
ElectricalPower Factor>0.9>0.9
Input Voltage120-277V AC, 50/60Hz120-277V AC, 50/60Hz
THD<20%<20%
Beam Angle120°120°
PhysicalWeight2.2KG2.5KG
Dimension285*195*100mm285*195*100mm
Housingdie-casting aluminumdie-casting aluminum
CoverPCPC
Mounting TypeWall MountedWall Mounted
Operation Temp.-35℃~+55℃　-35℃~+55℃　　
Finishblack paintedblack painted
IP Rating　IP65


Chip Temperature Test:
Great heat disspation, good for LED lifespan.
Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
Distribution Curve:
Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
Installation Instruction:
1. Dusk-to-dawn LED outdoor barn light luminaire features a design that can be mounted to any vertival surface using lag bolts or other comparable and suitable anchors, with a wiring compartment that is easily accessible without the need to remove the lens or disassemble the fixture.
2. Dusk-to-dawn LED outdoor barn light can also be mounted to existing 1-1/2'' or 1-5/8'' pipe mounts, offering the installer the flexibility to satisfy many different mounting appllications and requirements.
3. This is especially useful when using the LED outdoor barn light to retrofit older dusk-to-dawn laminaires.
Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
Packing: (2pcs / ctn)
Dusk-to-dawn LED outdoor barn LED Street Light LED Garden Light 35W-50W available with Photocell and PIR motien sensor
