Are you looking for an economical and easy to install insulating material? Look no further than Glass Wool Pipe Section! This material is not only lightweight but also boasts excellent heat and sound insulation capabilities, making it the perfect choice for extreme temperature conditions ranging from -85 degrees to 454 degrees.
Not only is Glass Wool Pipe Section a practical choice, it is also an environmentally friendly one. It is made from recycled glass and has low energy consumption during production. Its ability to reduce energy usage and save costs make it a wise investment for any project.
In addition to its insulating capabilities, Glass Wool Pipe Section is also resistant to fire, corrosion, and moisture, making it a durable choice for a range of applications. Its versatility lends itself well to industrial, commercial, and residential projects alike.
So next time you're in need of an insulating material, remember the many benefits of Glass Wool Pipe Section. Choose an economical, lightweight, and efficient option that will save you money in the long run.
Are you looking for an economical and easy to install insulating material? Look no further than Glass Wool Pipe Section ! This material is not only lightweight but also boasts excellent heat and sound insulation capabilities , making it the perfect choice for extreme temperature conditions ranging from -85 degrees to 454 degrees .
Not only is Glass Wool Pipe Section a practical choice, it is also an environmentally friendly one. It is made from recycled glass and has low energy consumption during production. Its ability to reduce energy usage and save costs makes it a wise investment for any project.
In addition to its insulating capabilities, Glass Wool Pipe Section is also resistant to fire, corrosion, and moisture , making it a durable choice for a range of applications. Its versatility lends itself well to industrial, commercial, and residential projects alike.
So next time you're in need of an insulating material, remember the many benefits of Glass Wool Pipe Section . Choose an economical, lightweight, and efficient option that will save you money in the long run.
The material used for this insulation is fiberglass, which has a water content of ≤1% and is resistant to chemicals. This product is available in two types: Pre-Slit and Unslit. The Glass Fiber Pipe Wrap is perfect for hot/cold water pipes, HVAC ducts, and steam pipes. It is easy to install and can help reduce energy costs by preventing heat loss.
There are many occasions and scenarios where the Fiberglass Pipe Cover can be used. For example, it is commonly used in commercial and residential buildings where there are water pipes or HVAC ducts. It can also be used in industrial settings where steam pipes are present. The insulation helps maintain a consistent temperature, which is important for the comfort of occupants and for the efficient operation of equipment.
The Fanryn Fiberglass Pipe Insulation is a versatile and effective product that can provide many benefits. It is a cost-effective solution that can help reduce energy costs and improve the performance of equipment. If you are in need of insulation for your pipes or ducts, consider the Fiberglass Pipe Cover from Fanryn.
Product parameter of the thermal insulation pipe
Recommend Thickness List(mm)
Pipeline System Type | The Thickness of glasswood pipe shell applied in different pipeline (mm) | ||||||
Liquid Temperature Range ℃ | Diameter of Branches Under 50mm | Under 25mm | 32-50 | 64-100 | 125-150 | Above 200mm | |
Air System Steaming and Water System High Temperature/ High Pressure System | 152-238 | 40 | 64 | 64 | 75 | 89 | 89 |
Medium Temperature/ Medium Pressure System | 122-151 | 40 | 50 | 64 | 64 | 75 | 75 |
low Temperature/ low Pressure System | 94-121 | 25 | 40 | 40 | 50 | 50 | 50 |
low Temperature System | 49-93 | 13 | 25 | 25 | 40 | 40 | 40 |
Steaming Condensator of Watering System | Any Temperature | 25 | 25 | 40 | 50 | 50 | 50 |
Equivalent Thickness of Surface Cooling Prevention
Environment Temperature | Relative Humidity | System Working Temperature | ||
2℃ | 7℃ | 13℃ | ||
38℃ | 50%-60% | 25 | 25 | 25 |
70% | 40 | 30 | 30 | |
80% | 75 | 60 | 50 | |
85% | 100 | 90 | 75 | |
32℃ | 50%-60% | 25 | 25 | 25 |
70% | 25 | 25 | 25 | |
80% | 50 | 50 | 40 | |
85% | 80 | 75 | 60 | |
27℃ | 50%-70% | 25 | 25 | 25 |
80% | 50 | 40 | 30 | |
85% | 75 | 65 | 50 | |
21℃ | 50%-70% | 25 | 25 | 25 |
80% | 50 | 40 | 30 | |
85% | 75 | 50 | 40 |
If the humidity exceeds 90%, some cooling water will appeared on the surface. In this condition, adding the
waterproofing coat or PVC plastic shell if necessary.
Product size of the glass wool pipe
Density(kg/m3) | Thickness(mm) | Length (mm) | Diameter (mm) |
48-80 | 25-90 | 1000,1200 | 18-529 |
Fiberglass Pipe Insulation is a thermal insulation material that is specifically designed for use in high-temperature applications. This type of insulation is made from inorganic fibers that are spun from molten glass and then formed into a flexible, lightweight material. The unique properties of fiberglass insulation make it an excellent choice for insulating pipes, ducts, and other equipment that operates at high temperatures.
Our technical support team is available to answer any questions you may have about the proper installation and use of fiberglass pipe insulation. We can provide guidance on selecting the right product for your specific application and offer advice on proper maintenance and repair.
In addition to technical support, we also offer a range of services to help ensure the proper functioning of your insulation system. These services include inspections, testing, and maintenance. Our team of experienced professionals can help identify any potential issues and provide solutions to keep your insulation system functioning at peak performance.
Product Packaging:
The Fiberglass Pipe Insulation is packaged in pre-formed sections or rolls, depending on the size and length required. The sections or rolls are then wrapped in plastic to protect them from moisture and other environmental factors. The packaged insulation is then labeled with product information, including size, length, and R-value rating.
Shipping:
The Fiberglass Pipe Insulation is shipped in sturdy cardboard boxes or pallets, depending on the quantity ordered. The boxes or pallets are carefully packed to ensure minimal movement during transit and to prevent any damage to the product. The boxes or pallets are labeled with shipping information, including product details, weight, and destination address.
Q1: What is the brand name of the Fiberglass Pipe Insulation?
A1: The brand name of our Fiberglass Pipe Insulation is Fanryn.
Q2: Where is the Fiberglass Pipe Insulation manufactured?
A2: Our Fiberglass Pipe Insulation is manufactured in China.
Q3: Is the Fiberglass Pipe Insulation certified?
A3: Yes, the Fiberglass Pipe Insulation is certified with SGS fireproof certificate.
Q4: What is the minimum order quantity for the Fiberglass Pipe Insulation?
A4: The minimum order quantity for the Fiberglass Pipe Insulation is 1*40 ft container.
Q5: What are the payment terms for ordering the Fiberglass Pipe Insulation?
A5: The payment terms for ordering the Fiberglass Pipe Insulation is 100% TT.
